Product Introduction

Main Unit
Cleaning On/Off
Short press to start cleaning Press
and hold to turn on or off
Circular indicator light
White: power ≥20%
Red: power ＜20%
Slow blinking: charging or launching
Red flash: fault status
Spot cleaning
Short press to start regional cleaning
Recharge
Short press to start recharging
Note:
Press any button to stop
the robotic vacuum during cleaning,
recharging, or spot cleaning
Reset WIFI
Press the spot cleaning button and
the recharge button at the same time
for 3 seconds
Open lid
Bumper
LDS cover
bumper sensor
5
Cliff sensor
*
LDS
Laser distance sensor
Wall sensor
Omni-directional
wheel
Charging contact pieces
Side brush
Main wheel
Main brush
Buckle of main
brush cover
