Roborock S5 Series Manual page 11

Installation
6 Start cleaning
When the circular indicator light on the main unit changes from slow
blinking to stable, charging is complete. Press
cleaning using the Mi Home app.
7 Remove the mopping module
When the main unit has returned to the charging dock after
cleaning, press the buckles on either side and pull out the
mopping module.
Note:
Use damp-proof mat if you put the charging dock on a wooden floor
Remove tank when charging or not in use
Operating Instruction
Main brush
1. Turn over the machine, press the buckle and take off the cover.
2. Take out the main brush in an upwards movement and
button or start
clean the main brush bearings
3. Use the supplied cleaning tool to cut entangled hairs and
remove them
4. Install the main brush, replace the cover, and snap the buckle.
Note: Replacing the main brush every 6-12 months is
recommended to ensure effective cleaning
9
*
Weekly cleaning is recommended
Main brush
Main brush cover
Buckle
Main brush bearing
