• 版本号： v2.0
• 修改时间： 2020.07.17 修改点： buttont
修改 button
历
• 修改人： 刘超
史
版
本
182mm
• 版本号： v3.0
• 修改时间： 2020.07.21
• 修改点： 修改封底 BEIJING 字母加 I
• 修改人： 刘超
石头科技产品包装图纸
图纸
北京石头科技有限公司
提供
单位
材质：105g 哑粉，骑钉
材
成品尺寸：182*130mm
质
页数：36P
工
参考色：PANTONE Cool Gray 11 C
艺
要
求
尺寸偏差：±0.5mm
印刷偏位：±1mm
130mm
备
注
项目名称
RUBYS-E 说明书 FCC 版本
料号
4.03.0249
版本号
V3.0
设计时间
2020.07.21
设计师
刘超
设计师
比例
PANTONE 185 C
1:1
单位
mm
Advertisement
Table of Contents
Related Manuals for Roborock S4 Max
Summary of Contents for Roborock S4 Max
- Page 1 石头科技产品包装图纸 图纸 北京石头科技有限公司 提供 单位 材质：105g 哑粉，骑钉 材 成品尺寸：182*130mm 质 页数：36P 工 参考色：PANTONE Cool Gray 11 C 艺 PANTONE 185 C 要 求 尺寸偏差：±0.5mm 印刷偏位：±1mm 130mm 备 注 项目名称 RUBYS-E 说明书 FCC 版本 料号 4.03.0249 版本号 V3.0 设计时间 2020.07.21 设计师 刘超...
- Page 2 Roborock S4 Max Robot Vacuum Cleaner User Manual Read this user manual carefully before using this product and store it properly for future reference.
-
Page 3: Safety Information
Safety Information IMPORTANT SAFETY INSTRUCTIONS When using an electrical appliance, basic precautions should always be followed, including the following: READ ALL INSTRUCTIONS BEFORE USING (THIS APPLIANCE), Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. WARNING To reduce the risk of fire, electric shock, or injury: •... - Page 4 • For use only with roborock CDZ11RR or CDZ12RR charger. Recharge only with the charger specified by the manufacturer. A charger that is suitable for one type of battery pack may create a risk of fire when used with another battery pack.
- Page 5 Safety Information • Do not expose a battery pack or appliance to fire or excessive temperature. Exposure to fire or temperature above 130°C may cause explosion. • Follow all charging instructions and do not charge the battery pack or appliance outside of the temperature range specified in the instructions.
- Page 6 Safety Information SAVE THESE INSTRUCTIONS Household use only. IMPORTANTES MESURES DE S CURIT L’utilisation d’un appareil électrique demande certaines précautions: LIRE TOUTES LES INSTRUCTIONS AVANT DE FAIRE FONCTIONNER (CETAPPAREIL), Le non-respect des mises en garde et des instructions peut causer des chocs électriques, des incendies et/ou des blessures graves.
- Page 7 à la position marche peut causer un accident. • Pour emploi seulement avec roborock CDZ11RR or CDZ12RR chargeur.Recharger uniquement avec le chargeur prescrit par le fabricant. Un chargeur convenant à un type de batterie peut présenter un risque d’incendie lorsqu’il est utilisé...
- Page 8 Safety Information l’appareil. Ces mesures de sécurité ont pour but d’éviter une mise en marche accidentelle de l’appareil. • Utiliser uniquement les batteries recommandées pour l’appareil. L’utilisation d’autres types de batteries peut présenter un risque de blessure ou d’incendie. • Lorsque l’appareil n’est pas utilisé, tenir la batterie loin d’objets métalliques comme des trombones, des pièces de monnaie, des clés, des clous, des vis ou autres petits objets qui pourraient établir une liaison entre les bornes.
-
Page 9: Laser Safety
Safety Information instructions d’utilisation et d’entretien. • Éloigner les cordons d’autres appareils de la zone à nettoyer. • Ne pas utiliser l’aspirateur dans une pièce où un nourrisson ou un enfant dort. • Ne pas utiliser l’aspirateur dans un endroit où il ya des bougies allumées ou des objets fragiles sur le plancher à... -
Page 10: Fcc Ic Statement
FCC IC Statement Compliance Information Product Name Robotic Vacuum Cleaner with Dock Charger Robotic Vacuum Cleaner Model: roborock S4 Max Produce Model Dock Charger Model: CDZ11RR or CDZ12RR This device complies with part 15 of the FCC Rules. This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada's licence-exempt RSS(s). - Page 11 FCC IC Statement Warning Any changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.
- Page 12 FCC IC Statement connected. —Consult the dealer or an experienced radio/TV technician for help. MPE Requirements To satisfy FCC / IC RF exposure requirements, a separation distance of 20 cm or more should be maintained between the antenna of this device and persons during device operation. To ensure compliance, operations at closer than this distance is not recommended.
- Page 13 Holiday Energy Saving Function When the robot is docked, press and hold "Recharge" for 10 seconds or until you hear an alert sound. This will activate Holiday mode. In this mode the robot will switch to Low Power mode to minimize power consumption. This includes a dimming of the LED indicator,and the stopping of all non-charging related functions including cleaning, remote control over WiFi, and more.
-
Page 14: Battery And Charging
Battery and Charging • Keep the dock charger away from heat (such as heating plates). • Do not wipe or clean the charging contact with a piece of wet cloth or wet hands. • Make sure the cleaner is powered off in shipment and original packaging is advised. •... -
Page 15: Product Introduction
Product Introduction Robot On/Off • Press to start cleaning • Press and hold to power on or off Power indicator • White: Battery level ≥ 20% • Red: Battery level < 20% • Flashing slowly: Charging or starting up • Flashing red: Error Dock/Spot Clean •... -
Page 16: Parts List
Product Introduction Parts list Charging dock Power cable... - Page 17 Product Introduction Dustbin Robot WiFi indicator light • Off: WiFi disabled Cover latch • Slow flashing: Waiting for connection • Fast flashing: Connecting Dustbin latch • Steady: WiFi connected System reset Air filter Air vent Main brush cleaning tool Speaker...
- Page 18 Product Introduction Robot and sensors Wall sensor Recharge sensor Cliff sensor Bumper Omnidirectional wheel Charging contact Laser distance Side brush sensor Main wheels Main brush Vertical Bumper Main brush cover latch...
- Page 19 Product Introduction Charging dock Charging dock power indicator Locator beacon Power socket Charging contact Charging contact...
-
Page 20: Installation
Installation Important Information Tidy cables and loose items from the ground and move any If using this robot in a raised area, always use a secure physical unstable, fragile, precious, or dangerous items to prevent barrier to prevent accidental falls that may result in personal personal injury or property damage due to items becoming injury or property damage. - Page 21 Installation Using the robot 1. Place the charging dock against the wall on a flat surface and plug it into the mains power. Double-sided tape Note: • Use of the double-sided tape to secure the charging dock is optional. • When necessary, remove the double-sided tape slowly to reduce residue glue. More than 0.5m (1.6ft) 3.
- Page 22 Download the Roborock app ① Note: Search "Roborock" in the App Store or Google Play, or scan • Due to ongoing app development, the actual process may differ slightly from the QR code below, then download and install the app.
- Page 23 Instructions for use On/off Note: • Cleaning cannot start if the battery level is too low. Allow the robot to charge before restarting cleanup. Press and hold the button to turn on the robot. The power • Tidy away any cables on the ground (including the power cable of the charging indicator will turn on and the robot will enter Standby mode.
-
Page 24: Spot Cleaning
Instructions for use Charging Note: If the robot is left connecting to the network for over an hour, its WiFi will be disabled. Reset WiFi before attempting reconnection. Auto: After cleaning, the robot will automatically return to the charging dock to recharge. Spot Cleaning Manual: In Pause mode, press the button to send the robot... -
Page 25: Cleaning Mode
Instructions for use Selective Room Cleaning Pin n Go Select specific rooms for cleaning in the app. In this mode, the Use the app to set a destination for the robot to go to. robot will only clean the selected rooms. Cleaning mode Use the app to choose from Quiet, Balanced, Strong, or MAX modes. -
Page 26: Charging Dock
Instructions for use Virtual No-go Zone and Invisible Wall More app functions The app can be used to draw Virtual No-go Zone and Invisible Wall Real-time map updates Carpet Boost Robot location to keep the robot from entering the areas you define. Part replacement Do Not Disturb (DND) Change cleaning mode... -
Page 27: Routine Maintenance
Routine maintenance Main brush Using the main brush cleaning tool *Clean weekly Use the main brush cleaning tool to remove any hair entangled 1. Turn the robot over then unlatch and remove the main brush around the main brush. cover. 2. - Page 28 Routine maintenance Dustbin and filter 2. Fill the dust bin with clean water and close the cover. Gently shake the dust bin, then pour out the dirty water. *Weekly cleaning is recommended 2. Open the dust bin lid as indicated by the arrow and pour out the contents.
-
Page 29: Side Brush
Routine maintenance Clean the washable filter Charging dock *Clean every two weeks *Monthly cleaning recommended 4. Rinse repeatedly and tap the filter frame to remove as much dirt Use a soft dry cloth to clean the charging contacts of the charging as possible. -
Page 30: System Reset
Routine maintenance Omnidirectional wheel System Reset *Clean as required If the robot does not respond when you press a button or the 1. Turn the robot over. robot cannot be shut down, press the Reset button. The robot will 2. Use a small screwdriver to pry out the axle and remove the then restart. -
Page 31: Firmware Update
Routine maintenance Robot sensors Firmware update *Clean monthly Update the robot using the app. Place the robot on the charging Use a soft dry cloth to wipe and clean all sensors, including: dock and ensure that the battery level is higher than 20% before 1. -
Page 32: Basic Parameters
Basic parameters Robot Charging dock Name Parameters Name Parameters Model roborock S4 Max Model CDZ11RR or CDZ12RR Dimensions 350 x 350 x 96.5mm Dimensions 151 x 130 x 98mm Battery 14.4V/5200mAh lithium battery Rated power Weight Approx. 3.3kg Rated input... -
Page 33: Troubleshooting
Troubleshooting If an error occurs during the cleanup, the power indicator will flash red quickly, and a voice alert will play. Refer to the table below for resolution options. Error Solution Error 1: Rotate the laser head to check that it turns The LDS unit is jammed. - Page 34 Malfunction due to an internal error. Reset the system. Note: A system reset may not resolve all problems. If the problem persists after using the recommendations in the table above, please email our after-sales service team: US/Non-Europe Support: support@roborock.com Europe Support: support@roborock-eu.com...
- Page 35 Unable to connect to WiFi The current device is not supported. You can find supported models inside the app. Unable to connect to WiFi. There may be an error with your router settings. Contact Roborock customer service for help with troubleshooting.
- Page 36 FAQs Problem Solution The battery level is too low. Scheduled cleaning can only begin when the battery level is Scheduled cleaning is not working above 20%. Is power always being drawn when the The robot will draw power while it is docked to maintain battery performance, but power robot is on the charging dock? consumption is extremely low.
- Page 37 Address of Manufacturer: Floor 6, Suite 6016, 6017, 6018, Building C, Kangjian Baosheng Plaza, No.8 Heiquan Road, Haidian District, Beijing, P.R.CHINA For more product information, visit our website: www.roborock.com For after-sales support, email our after-sales service team: US/Non-Europe Support: support@roborock.com...
