Using the TMA 1600-III
I. Installing the TMA 1600-III
1. Make sure that the scanner power is turned off.
2. Attach the TMA 1600-III by sliding the posts at the rear of the TMA 1600-III into the holes.
3. Plug the connector of the TMA 1600-III into the
scanner's 15-pin accessory port.
II. Unlocking the TMA 1600-III
1. Remove the yellow "Step 3" sticker from the
TMA 1600-III.
2. Look for the locking knob at the base of the
TMA 1600-III.
3. Turn the locking knob counterclockwise to the
unlock position " ".
NOTE: If you need to transport your TMA 1600-III, you will have
to lock it back. For more details, refer to "ArtixScan 3200XL User
Guide" in your Microtek Software CD/DVD.
TMA 1600-III
