- Page 1 F900 SERIES User, installation and servicing instructions RISE and FALL GRILL E600 Read these instructions before use DATE PURCHASED: MODEL NUMBER: SERIAL NUMBER: DEALER: SERVICE PROVIDER: T100913 REV. 3...
- Page 2 Dear Customer Thank you for choosing Falcon Foodservice Equipment. This manual can be downloaded from www.falconfoodservice.com or scan here: IMPORTANT: Please keep this manual for future reference. Falcon Foodservice Equipment HEAD OFFICE Wallace View, Hillfoots Road, Stirling. FK9 5PY. Scotland.
- Page 3 SYMBOLS SCREWDRIVER SPANNER COOKING OIL GREASE WARNING SPARK IGNITION FLAME VIEWPORT ALLEN KEY IGNITER C SPANNER REMOVE DEVICE PLUG REMOVER...
- Page 4 Ensure the supply cord is routed free from the appliance to avoid damage. The appliance has been designed and approved to use Falcon kick plates; non Falcon kick plates could potentially adversely affect the performance of the appliance by restricting the air to the appliance.
- Page 5 Training and competence To help ensure the safe use of this appliance there is a requirement for you to provide whatever information, instruction, training and supervision as is necessary to ensure, so far as is reasonably practicable, the health and safety of all users. For further help and information on training and competence we would refer you the Health and Safety Executive website;...
-
Page 6: Table Of Contents
THE MANUFACTURER RESERVES THE RIGHT TO MODIFY WITHOUT NOTICE THE APPLIANCE CHARACTERISTICS DESCRIBED IN THIS HANDBOOK. CONTENTS 1. INSTALLATION IMPORTANT INFORMATION POSITIONING CONNECTING TO THE MAINS 2. INSTRUCTIONS FOR E600 FUNCTIONING SETTING USER INTERFACE MANUAL MODE 3. CLEANING AND MAINTENANCE ROUTINE MAINTENANCE... -
Page 7: Installation
SECTION 1 INSTALLATION IMPORTANT INFORMATION Read this handbook through carefully as it provides important information about safely installing, using and servicing the unit. Keep the handbook in a safe place for future reference by the various operators. The unit must be installed by professionally qualified personnel in accordance with the ·... - Page 8 CONNECTING TO THE MAINS Electrical rating: 4.5kW Electrical supply voltage: 400V 3N~ 50/60hz Required electrical supply: 32A Phase split: L1 6.52A, L2: 6.52A. L3: 6.52A Single phase: 19.56A Before connecting unit to the mains, check that both voltage and frequency on rating plate are the same as those of the electrical supply system.
-
Page 9: Instructions For E600
SECTION 2 INSTRUCTIONS FOR E600 (fitted with plate) The unit should only be used for the designated purpose. Any other use is improper. Do not leave appliance unattended when in use. Figure 3 GRILL FUNCTION COOKING mode: By adjusting the hood height, it is possible to regulate heat upon food to be cooked. -
Page 10: Manual Mode
Mode select button allows you to select either cooking or hold modes in case of manual cooking; in case of program selection you can pass from cooking mode to hold mode and vice versa. - and + buttons increase or decrease cooking time and/or heat intensity of the hold mode Central heating button allows you to set the cooking session with all resistances or just the central resistances. -
Page 11: Cleaning And Maintenance
SWITCHING OFF After use, switch off appliance using ON/OFF switch and omni-polar switch upstream of appliance. SECTION 3 CLEANING AND MAINTENANCE 3.1 ROUTINE MAINTENANCE At the end of each working day, the unit must be cleaned both for reasons of hygiene and also to prevent malfunctions. - Page 12 WIRING DIAGRAM L1 L2 L3 N 400V 3N~ 50/60hz 230V~ 50/60hz ----@£ ----lfiig ----lfiig .::::. l... S :. "' "' "' "' "' • 11 • 31 ] 21 -\-,4--\-;4--\ 24 D--:14--134--)24 .::::. " " " 4 --------------------------------------- ----o -----------------0 ---0---- SCH1 MAIN BOARD 0 ..-...
