User, installation and servicing instructions
BOILING PAN
F900 SERIES
E9781
Read these instructions before use









REV. 5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F900 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Falcon F900 Series

  • Page 1 F900 SERIES   User, installation and servicing instructions BOILING PAN E9781     Read these instructions before use        DATE PURCHASED:     MODEL NUMBER:   SERIAL NUMBER: DEALER: SERVICE PROVIDER: T100951 REV. 5...
  • Page 2 Dear Customer, Thank you for choosing Falcon Foodservice Equipment. This manual can be downloaded from www.falconfoodservice.com or scan here. IMPORTANT: Please keep this manual for future reference. Falcon Foodservice Equipment HEAD OFFICE Wallace View, Hillfoots Road, Stirling. FK9 5PY. Scotland.
  • Page 3          These instructions are only valid if the country code appears on the appliance. If the code does not appear on the appliance, refer to the technical instructions for adapting the appliance to the conditions for use in that country.
  • Page 4 (RCD).    The appliance has been designed and approved to use Falcon kick plates, non Falcon kick plates could potentially adversely affect the performance of the appliance by restricting the air to the appliance. IMPORTANT INSTALLATION INFORMATION...
  • Page 5: Table Of Contents

    Part 1: General reminders and notes  1.1  General reminders  1.2  Technical data  1.3  Construction  1.3.1  Details only for pressure kettles  1.4  Laws, technical prescriptions and directives  1.5  Special requirements for the installation site  Part 2: Positioning, installation and maintenance  2.1  Positioning  2.2  Installation  2.2.1  Electrical connections and equipotential bonding  2.2.2  Connection to waterworks  2.3  Commissioning and testing  2.4  Maintenance of the appliance  Possible failures and their elimination   2.4.1  Part 3: Use and cleaning  3.1  Warnings and hints for user  3.2  Instructions for use  3.2.1  Filling the jacket   3.2.2  Details regarding the operation of the pressure kettles  3.2.3  Switch on, start of cooking and switch off  3.3  Cleaning and care of the appliance ...
  • Page 6: Part 1: General Reminders And Notes

    Section 1: General reminders and notes    1.1 GENERAL REMINDERS  Read the warnings contained in this manual carefully as they provide important information  concerning safety during the installation, use and maintenance of the appliance.  Keep these instructions safe for reference!  Only personnel trained specifically to use the equipment should operate it.  Keep appliance under control during use.  The appliance should be used only for the purpose for which it has been specifically designed;            other uses are improper and hence dangerous.  During operation surfaces can become hot and require special operation.  Unplug appliance in case of failures or improper operation.  Apply exclusively to a service centre for repairs or maintenance.  Any important information about the appliance required for technical service is contained in the  technical data plate (see figure “View of appliance”).   If technical assistance is required, the problem must be described in as much detail as possible,         so that a service technician will be able to assist with solving it.  Gloves should be worn during installation and maintenance operations.    Warning! :  Follow the fire prevention regulations very carefully.    1.2 TECHNICAL DATA    1.2. Technical data Description  Unit of  100LT 150LT  measurement  Width   mm  Depth   mm  Height   mm  PAN diameter  mm  PAN height  mm  540  Total volume ...
  • Page 7: Construction

    1.3 CONSTRUCTION  Main structure is AISI 430 with 4 adjustable feet.  Panels are stainless steel AISI 304, thickness 10‐12/10.  Stainless steel pan is AISI 316, thickness 20/10.  Chrome‐plated brass drainage tap.  Lid is stainless steel, hinged and spring‐balanced in all opening positions.  Stainless steel jacket and lining is AISI 304, thickness 15‐20/10.  Heating system comprising shielded heating elements made from “Incoloy‐800” alloy with boiler and  steam circulation.  Jacket pressure is controlled by a safety valve set at 0.5 bar; appliance is equipped with an analogue  pressure gauge.  Water connection is 3/4".  Safety thermostat will cut power in the event of a problem.  The appliance is equipped with a three‐position selector with three heating functions:  Position “0”   Heating not activated   Position “1”   Reduced power (50%)   Position “2”   Full power (100%)    Operating thermostat for temperature adjustment is located inside cooking pan.    1.3.1 DETAILS ONLY FOR PRESSURE KETTLES  Stainless steel lid is supplied with heat‐resistant silicone gasket.  Hermetic closing of lid is ensured by 4 screw clamps.  The relief valve for the pressure that develops inside the cooking pan is set at 0.05 bar.  On request, the appliance can be supplied with a pressure gauge that will indicate the pressure  inside the cooking pan.    1.4 LAWS, TECHNICAL PRESCRIPTIONS AND DIRECTIVES  When installing the appliance it is necessary to follow and comply with the following regulations:  Current regulations on the matter;  Hygienic‐sanitary regulations concerning cooking environments;  Municipal and/or territorial building regulations and fire prevention prescriptions;  Current accident prevention guidelines;  Electricity board regulations concerning safety;  Regulations of the electrical power supply company or agency;  Other local regulations.    1.5 SPECIAL REQUIREMENTS FOR THE INSTALLATION SITE  The room in which the appliance is to operate must be well ventilated.  In addition, it is good policy to locate the appliance under an extractor hood so that cooking vapours  can be removed rapidly and continuously.  ...
  • Page 8: Part 2: Positioning, Installation And Maintenance

    Part 2: Positioning, installation and maintenance    2.1 POSTIONING  Remove all packaging and check that the appliance is in perfect condition.   In case of visible damage, do not connect the appliance and notify the sales point immediately.  Remove PVC protection from all panels.  Dispose of packaging according to regulations. Generally material is divided according to  composition and should be delivered to the waste disposal service.  There are no special instructions regarding distances from other appliances or walls however, it is  advisable to maintain a sufficient distance to allow any service function to be carried out. In the  event that the appliance is installed in direct contact with flammable walls, it will be necessary to fit  suitable heat insulation.  The appliance must be levelled. Small differences in level can be achieved by adjusting the legs as  required. A significantly uneven surface or sloping may adversely affect operation of the appliance.     2.2 INSTALLATION  Warning! : Only qualified technicians must perform the installation, maintenance and testing of the  appliance.  Warning! : Before connecting any parts of the appliance to supplies, make sure that the supplies are  equivalent to requirements stated on the unit data plate, if appliance has been designed to operate  on these supplies.    2.2.1 ELECTRICAL CONNECTIONS AND EQUIPOTENTIAL BONDING  Warning! : The appliance operates in accordance with power supply indicated on the data plate.   As mentioned, appliance must be connected to power supply by way of a multiple pole main  isolating switch and protection device that must be proportioned to the power of the appliance  (1mA per kW of rated power).  The earthing system must be efficient.  This appliance is type X equipment (delivery without power cable and plug), the cable and other  hardware needed to connect to the electrical power supply must be provided by the installer.   The power cable shall be of type described in the paragraph “Technical data" and shall be resistant  to oil.  Power terminal board can be reached by removing lower front panel (undo fixings). The cable  fastener is located at lower right‐hand side.  The cable must be fed in from below clamp. The individual wires are then fastened to corresponding  terminals of terminal board. The earth wire must be longer than the other cables, so that in the  event of this being jerked or the clamp broken, live wires will disconnect first. Lock cord fastener.  The appliance must incorporate an equipotential system.  Connect terminal on lower right‐hand side marked with the international symbol to a connector with  a nominal cross section <10 mm.   All appliances being installed will be connected using this earthing system. ...
  • Page 9: Commissioning And Testing

    2.3 COMMISSIONING AND TESTING  When all connections have been made, the appliance and the overall installation must be checked  following the directions given in this manual.  Check the following points:  Protective film has been removed from the external surfaces.  The lower front panel removed for the electrical connection has been replaced.  Connection has been made in accordance with the requirements and directions indicated in this  manual.  All safety requirements in current standards, statutory regulations and directives have been met.  Water connections are leak‐free.  Electrical connection has been completed according to standards.  In addition, check that when unit has been installed, the mains cable is not subject to stretching or  that it is not in contact with any hot surface.  Proceed to light the appliance as directed in the instructions for use.  While appliance is in use, voltage should not differ from the nominal voltage more than +/‐ 10%.  The test report must be completed in full and submitted to customer who should then sign in  acceptance.   With effect from this moment, the appliance is covered by the manufacturer’s warranty.    2.4 MAINTENANCE OF THE APPLIANCE  Warning! : All maintenance operations shall only be performed by a qualified service engineer!  To ensure correct and safe operation, the unit must be inspected and serviced at least once  annually. Maintenance should also include checking the condition of pipes, feed pipes, electrical  components etc.  It is advisable to replace worn components during maintenance to avoid the need for further calls or  unexpected failures.  It is also advisable to arrange a maintenance contract with a certified service agent.    2.4.1 POSSIBLE FAILURES AND THEIR ELIMINATION  Warning! :  Only qualified service engineers should perform the operations described below!  Warning! :  Before resetting safety thermostat, it is necessary to eliminate the cause of activation!    Problem and Possible Cause   Access to Components and Operation  The pan contents do not heat up:  Safety thermostat   The safety thermostat can be accessed after lower front panel  Safety thermostat has been activated;   has been removed.  ...
  • Page 10: Part 3: Use And Cleaning

    Section 3: Use and cleaning    3.1 WARNINGS AND HINTS FOR USER  This manual contains all the instructions required for a proper and safe use of our appliances.  Keep the manual in a safe place for future consultation!  This appliance is for catering use and must be used only by trained kitchen staff.  The appliance must always be kept under control during use.  Warning! : The manufacturer shall not be held responsible for injuries or damage due to non‐ compliance with safety rules or improper operator use of the appliance.   Improper operating conditions may be caused by improper use. It is important to train personnel  properly.  All installation and maintenance operations must be performed by registered engineers.  Respect the periods required for maintenance. With this is mind, customers are recommended to  sign a service agreement.  In case of failures concerning the appliance, all supplies (electrical and water) must be cut off  instantly.  In case of recurrent failures, contact a service engineer.    3.2 INSTRUCTIONS FOR USE  Before cooking with the appliance for the first time, wash the pan interior thoroughly.  Warning! : Fill pan up to a maximum of 40mm below overflow mark according to the maximum level  indicator, including the food to be cooked.  Warning! : Before filling pan, always check that the drainage tap is closed.    3.2.1 FILLING THE JACKET   Warning! The water level in the jacket must be checked each time before lighting.   Warning! It is advisable to use softened water to fill the jacket!     3.2.1. FILLING THE JACKET – MOD. 100‐150LT  Open level tap at appliance front.    Undo filling cap on safety valve unit. This is located on the right of the appliance front (see diagram).    10   ...
  • Page 11: Switch On, Start Of Cooking And Switch Off

    Fill with softened water (the capacity of the jacket is stated in the “Technical data” section).  When water starts to pour out of the level tap, close tap and replace safety cap.  3.2.2 DETAILS REGARDING OPERATION WITH PRESSURE KETTLE  Before turning unit on, close lid firmly and lock 4 screw clamps.   Check relief valve is in rest position.  Start cooking at full power. When steam starts to emit from valve, reduce heating power.                Steam emitting from valve must be constant and light.   Pressure inside pan may reach a maximum of 0.05 bar. Upon request, appliance can be supplied with  a pressure gauge to indicate pressure inside pan.  Turn appliance off after cooking.  Before opening lid, release all pressure from pan by lifting relief valve lever (see figure “Controls”).  Check that valve lever is still "ON" and undo screw clamps.    3.2.3 SWITCHING ON, START COOKING AND SWITCHING OFF  Fill pan with hot or cold water, according to need, using tap that appliance is equipped with.  The unit has a three‐position selector to start cooking functions (see figure “Controls" on Page).  Here is a list of the procedures for a safe and correct use of the appliance.  Energising the unit:  Turn ON appliance at main switch.  Start of cooking:  Turn control from position “0” to required heating position according to cooking requirements.  Green neon will light.  Cooking is generally started with control set to position “2”; when pan reaches cooking temperature,  turn control to “1” to maintain this.  Set operating thermostat knob to desired temperature between 40 and 100°C.  Heating will start and orange neon will light automatically.  Orange neon will go out as soon as set temperature is reached.  To make water boil quickly, set control to a temperature of 100°C.  Heating elements operate continuously.  By turning selector from Position “2” to “1”, it is possible to keep water boiling using less power.    3.3 CLEANING AND CARE OF THE APPLIANCE  Do not use aggressive substances or abrasive detergents when cleaning stainless steel components.  Avoid using metal pads on steel parts as these may cause rust. For the same reason, avoid contact  with materials containing iron.  Do not use sandpaper or abrasive paper for cleaning; in special cases use a powder pumice stone.  In case of particularly resistant dirt, it is advisable to use abrasive sponges (e.g. Scotch‐Brite).  It is only advisable to clean the appliance only when it has cooled down.    3.3.1 DAILY CLEANING  Warning! :  When cleaning appliance, never use a direct jet of water to prevent infiltration of the ...
  • Page 12: Special Procedures In Case Of Failures

    3.4 SPECIAL PROCEDURES IN CASE OF PROLONGED INACTIVITY  If appliance is to be idle for any length of time (e.g. holidays or seasonal closing) it must be cleaned  thoroughly leaving no trace of food or dirt.   Leave lid open so that air can circulate inside pan.  For added care after cleaning, protect external surfaces by applying a proprietary metal polish.  Be absolutely sure to shut off all utilities (electrical power and water).  Air the room appropriately.    3.5 SPECIAL PROCEDURES IN CASE OF FAILURES  If appliance should not work properly during use, turn it off immediately and close or cut off all  supplies (electrical power and water). Apply to a service centre for assistance.    The manufacturer shall not be held responsible nor has any warranty commitments for damage  caused by non‐compliance with prescriptions or by installation not in conformity with instructions.  The same applies in case of improper use or different application by the operator.    3.6 HOW TO PROCEED, IF…  Warning! :  Problems and failures may occur even when the appliance is used properly. Here is a list  of the most probable situations and solutions that an operator should perform to avoid making an  unnecessary service call.    If this does not solve the problem, turn appliance off immediately and unplug it. Isolate electrical  and water supplies and call a service agent.       Pan contents do not heat up:  check power ON/OFF switch is on;   otherwise, turn off appliance and call a service agent. The safety  thermostat  may  have  been  activated  due  to  excess  pan  temperature.  This  may  occur  when  unit  is  turned  on  and  pan and/or jacket is/are empty. ...
  • Page 13: Part 4: Figures And Details

    Part 4: Figures and Details  4.1 WIRING DIAGRAM (400V)    C1       Electromagnetic switch MAX.   R1      Heating element  L1       Green operation light     SE       Selector   L2       Orange warning light     TL       Operating thermostat  MA     Line terminal board     TS       Safety thermostat   F2        Fender‐fuse 3.15A     C2       Electromagnetic switch  MIN.            C3       Electromagnetic switch 30A security      * =  SENSOR FOR SAFETY THERMOSTAT                    13   ...
  • Page 14 4.1  WIRING DIAGRAM (230V)    C1      Electromagnetic switch MAX.            R1          Heating element   L1      Green operation light                          SE           Selector  L2      Orange warning light                          TL           Operating thermostat  MA    Line terminal board                    TS           Safety thermostat   F2       Fender‐fuse 3.15A                               C2          Electromagnetic switch MIN.  C1‐S   Electromagnetic switch security       C2‐S       Electromagnetic switch security    * =  SENSOR FOR SAFETY THERMOSTAT                                14   ...
  • Page 15: View Of Appliance

    4.2 VIEW OF APPLIANCE    E ‐ Electrical connection  S – Overflow  A ‐   Water connection               1. Selector    2. Green warning light      3. Pressure gauge  4. Cooking pan drainage tap  5. Pan water feed tap  6. Jacket level tap  7. Orange warning light  8. Operating thermostat          15   ...
  • Page 16: Controls

    4.3 CONTROLS             Position 0 = Off  Position 1 = 50% power   Position 2 = 100% power      4.3.1 OPERATING THERMOSTAT                            A ‐ OFF                                                                                             B ‐ MAX      4.4 RELIEF VALVE (PRESSURE KETTLE ONLY)          Valve in operating            position                            Valve in open position  16   ...
