- Page 1 F900 SERIES User, installation and servicing instructions PASTA COOKER E9241 Read these instructions before use DATE PURCHASED: MODEL NUMBER: SERIAL NUMBER: DEALER: SERVICE PROVIDER: T100900 Rev 9 Published: 02/10/2018...
- Page 2 Dear Customer Thank you for choosing Falcon Foodservice Equipment. This manual can be downloaded from www.falconfoodservice.com or scan here: IMPORTANT: Please keep this manual for future reference. Falcon Foodservice Equipment HEAD OFFICE Wallace View, Hillfoots Road, Stirling. FK9 5PY. Scotland.
- Page 3 SYMBOLS SCREWDRIVER SPANNER COOKING OIL GREASE WARNING SPARK IGNITION FLAME VIEWPORT ALLEN KEY IGNITER C SPANNER...
- Page 4 We recommend supplementary electrical protection with the use of a residual current device (RCD). The appliance has been designed and approved to use Falcon kick plates; non Falcon kick plates could potentially adversely affect the performance of the appliance by restricting the air to the appliance.
-
Page 5: Table Of Contents
CONTENTS APPLIANCE INFORMATION ..................1 OPERATION ......................2 COMPONENT PARTS ..................2-3 CONTROLS ......................4 USING THE APPLIANCE ..................5 CLEANING AND MAINTENANCE ................6 CLEANING AND MAINTENANCE ................6 SPECIFICATION ......................7 APPLIANCE WEIGHT TABLE ................7 TECHNICAL DATA TABLE ..................7 DIMENSIONS / CONNECTION LOCATIONS ............ -
Page 6: Appliance Information
1.0 APPLIANCE INFORMATION This appliance has been CE-marked on the basis of compliance with the relevant EU directives for the heat inputs, gas pressures and voltages stated on the data plate. A - Serial No B - Model No C - Flue Type D - Gas Category E - Gas Pressure F - Gas Type... -
Page 7: Operation
2.0 OPERATION 2.1 COMPONENT PARTS... - Page 8 DOOR FILLER SPOUT ELEMENT ROTATING HANDLE WATER TAP RESET SWITCH DRAIN HANDLE CLOSED ON/OFF SWITCH WIRE GRID POWER NEON DRAIN SHELF HEAT DEMAND NEON SAFETY & OPERATING THERMOSTAT TEMPERATURE CONTROL ELEMENT...
-
Page 9: Controls
2.2 CONTROLS ON/OFF SWITCH TEMPERATURE CONTROL POWER NEON (RED) HEAT DEMAND NEON (AMBER) DRAIN VALVE... -
Page 10: Using The Appliance
2.3 USING THE APPLIANCE 2.3.1 Before use, clean the appliance inside and out. See section 3 2.3.2 Ensure drain valve is closed; fill with water to marked level. 2.3.3 Switch power on, 1. 2.3.4 Set temperature control 4 to desired setting. IF THE UNIT TURNS OFF, PRESS RESET BUTTON 2.3.5 To switch the unit off, turn temperature control 4 to `off` position. -
Page 11: Cleaning And Maintenance
3.0 CLEANING AND MAINTENANCE 3.1 CLEANING AND MAINTENANCE 3.1.1 Turn off and allow cool down. 3.1.2 Drain water and remove grid. 3.1.3 Rotate element if required to clean pan. ELEMENT ROTATING HANDLE GRID 3.1.4 Remove other debris using a cloth. FAILURE DUE TO LACK OF PROPER CLEANING IS NOT COVERED BY WARRANTY. -
Page 12: Specification
4.0 SPECIFICATION 4.1 APPLIANCE WEIGHT TABLE APPLIANCE UNIT WEIGHT (kg) PACKED WEIGHT (kg) E9241 4.2 TECHNICAL DATA TABLE CURRENT POWER MIN (A) (-5) MAX (A) (+5) DESIRED (A) PHASE (Kw) @ 230V @ 230V @ 230V @ 230V 10.83 12.63 12.1... -
Page 13: Dimensions / Connection Locations
5.0 DIMENSIONS / CONNECTION LOCATIONS... -
Page 14: Installation
6.0 INSTALLATION Electrical Safety and Advice Regarding Supplementary Electrical Protection Commercial kitchens and foodservice areas are environments where electrical appliances may be located close to liquids, or operate in and around damp conditions, or where restricted movement for installation and service is evident. The installation and periodic inspection of the appliance should only be undertaken by a qualified, skilled and competent electrician;... -
Page 15: Assembly
6.2 ASSEMBLY 6.2.1 Position appliance and level using feet adjusters as shown below. 6.2.2 Fit anti tilt device as shown below. -
Page 16: Electric Supply & Connection
6.3 ELECTRIC SUPPLY & CONNECTION 6.3.1 The location of the electrical inlet is as seen in section 5.0. This unit is suitable for AC supplies only. The standard terminal arrangement is Three phase (400V 3N~) for all variants. 6.3.2 A suitable supply cord is supplied that conforms to code designation 60245 IEC 57, cable specification H07RN-F 5G2.5 or (H07RN-F 3G6 for single phase appliance).This appliance is designed to, and must, be connected to fixed wiring. -
Page 17: Suiting
The DLS system is designed to give a quick and easy suiting solution. If you require an improved seal between appliances we recommend you use, a food grade, high temperature silicon sealant. This can be supplied by Falcon part no – 523400021... - Page 18 6.5.5 Run a bead of silicon 5mm from profile edge as highlighted below. 6.5.6 Slide suited units into position 6.5.7 (A) Right hand unit: Screw the M5 x 40 screw (supplied in the kit) into one of the suiting plates as shown and then insert through the front fixing holes of both units. 6.5.8 (B) Left hand unit: Slide the penny and lock washer on to the screw and secure using the M5 nut.
- Page 19 6.5.10 (D) Replace fixings on the rear hob and tighten screw caps into position. 6.5.11 Replace control panel.
-
Page 20: Servicing
7.0 SERVICING BEFORE ATTEMPTING ANY MAINTENANCE, ISOLATE THE APPLIANCE AT THE MAINS SWITCH AND TAKE STEPS TO ENSURE THAT IT IS NOT INADVERTENTLY SWITCHED ON. 7.1 DOOR REMOVAL 7.1.1 Remove door as shown. -
Page 21: Temperature Control & Tap Removal
7.2 TEMPERATURE CONTROL & TAP REMOVAL 7.2.1 Remove as shown. 7.3 CONTROL PANEL REMOVAL 7.3.1 Remove as shown... -
Page 22: Switch Panel Removal
7.4 SWITCH PANEL REMOVAL 7.4.1 Remove as shown. 7.5 OPERATING & SAFETY STAT REMOVAL 7.5.1 Remove thermostats as shown. -
Page 23: Element Cover Removal
7.6 ELEMENT COVER REMOVAL 7.6.1 Remove as shown. 7.7 ELEMENT REMOVAL 7.7.1 Remove handle as shown. - Page 24 7.7.2 Remove ring nut and safety switch as shown. 7.7.3 Remove element as shown...
-
Page 25: Tap Removal
7.8 TAP REMOVAL 7.8.1 Remove as shown. 7.8.2 Replace all parts in reverse order. -
Page 26: Circuit Diagrams
7.9 CIRCUIT DIAGRAMS 7.9.1 Diagram... - Page 27 7.9.2 Diagram (Single Phase)
-
Page 28: Wiring Diagrams
7.10 WIRING DIAGRAMS 7.10.1 E9241 Diagram... -
Page 29: Accessories
8.0 ACCESSORIES 8.1 BASKETS AND BASE PANEL 8.1.1 Left hand basket 1/6 8.1.2 Right hand basket 1/6 8.1.3 Basket 1/3... -
Page 30: Fault Finding
8.1.4 Perforated base panel 9.0 FAULT FINDING FAULT POSSIBLE CAUSES REMEDY Unit will not turn ON No Power to unit Check power supply is connected & turned ON Unit will not operate Unit not switched On Turn unit On inside door Unit will not switch On Element not in base off pan Make sure element in down... -
Page 31: Spare Parts
10.0 SPARE PARTS PART DESCRIPTION SPARES NUMBER Temperature control knob On/off switch Power neon red Heat demand neon amber Filler spout Element assembly Element O ring small Thermostat control Safety thermostat Safety switch (element tilt switch) Control knob Control panel Dust cover Drain shelf When ordering spare parts please quote the following:...
