- Page 1 F900 SERIES User, installation and servicing instructions PASTA COOKER E9241 Read these instructions before use DATE PURCHASED: MODEL NUMBER: SERIAL NUMBER: DEALER: SERVICE PROVIDER: T100900 REV 6 Published: 08.09.16...
- Page 2 Dear Customer, Thank you for choosing Falcon Foodservice Equipment. This manual can be downloaded from www.falconfoodservice.com or scan here. IMPORTANT: Please keep this manual for future reference. Falcon Foodservice Equipment HEAD OFFICE Wallace View, Hillfoots Road, Stirling. FK9 5PY. Scotland.
- Page 3 SYMBOLS. • SPANNER • SCREWDRIVER • COOKING OIL • GREASE • SPARK IGNITION • FLAME • WARNING • VIEWPORT • ALLEN KEY •IGNITER •C SPANNER...
- Page 4 The Appliance has been designed and approved to use Falcon Kick plates; non Falcon kick plates could potentially adversely affect the performance of the appliance by restricting the air to the appliance.
-
Page 5: Table Of Contents
CONTENTS 1.0 APPLIANCE INFORMATION ..................... 6 2.0 OPERATION ..........................7 COMPONENT PARTS ....................... 7 CONTROLS ..........................8 USING THE PASTA COOKER ..................... 8 3.0 CLEANING AND MAINTENANCE .................... 9 4.0 SPECIFICATION ......................... 9 5.0 DIMENSIONS / CONNECTION LOCATIONS ..............10 6.0 INSTALLATION ......................... -
Page 6: Appliance Information
1.0 APPLIANCE INFORMATION This appliance has been CE-marked on the basis of compliance with the relevant EU directives for the heat inputs, gas pressures and voltages stated on the data plate. A - Serial No B - Model No C - Flue Type D - Gas Category E - Gas Pressure F - Gas Type... -
Page 7: Operation
2.0 OPERATION 2.1 COMPONENT PARTS A - DOOR B - ELEMENT ROTATING HANDLE C - RESET SWITCH D - ON/OFF SWITCH E - POWER NEON F -HEAT DEMAND NEON G - TEMPERATURE CONTROL H -FILLER SPOUT I -WATER TAP J - DRAIN HANDLE CLOSED K -WIRE GRID L - DRAIN SHELF M -SAFETY &... -
Page 8: Controls
2.2 CONTROLS 1- On/Off switch 2- Power neon (red) 3- Heat demand neon .(amber) 4- Temperature control 5- Tap 6- Drain valve 2.3 USING THE PASTA COOKER 2.3.1 Before use, clean the appliance inside and out. See section 3. 2.3.2 Ensure drain valve is closed;... -
Page 9: Cleaning And Maintenance
3.0 CLEANING AND MAINTENANCE Turn off and allow cool down. Drain water and remove grid. Rotate element if required to clean pan. 1- Element rotating handle 2- Grid Remove other debris using a cloth. FAILURE DUE TO LACK OF PROPER CLEANING IS NOT COVERED BY WARRANTY. -
Page 10: Dimensions / Connection Locations
Phase Actual (A) 10.83 12.63 12.1 10.83 12.63 12.1 10.83 12.63 12.1 Note if any current is out with these tolerances, the cause must be investigated and rectified 5.0 DIMENSIONS / CONNECTION LOCATIONS... -
Page 11: Installation
6.0 INSTALLATION 6.1 SITING / CLEARANCES CAUTION: WALLS CLOSER THAN 150mm TO THE APPLIANCE MUST BE NON COMBUSTABLE. IF SUITING THE NECESSARY CLEARANCES TO ANY CUMBUSTIBLE WALL MUST BE THE LARGEST FIGURE GIVEN FOR INDIVIDUAL APPLIANCES INSTRUCTIONS. 6.2 ASSEMBLY 6.2.1 Position appliance and level using feet adjusters as shown below. Fit anti tilt device. - Page 12 6.2.2 Connect appliance to mains supply...
-
Page 13: Suting Of Units
This can be supplied by Falcon part no – 523400021 6.3.5 Run a bead of silicon 5mm from profile edge as highlighted below. - Page 14 6.3.6 Slide suited units into position 6.3.7 (A) Right hand unit: Screw the M5 x 40 screw (supplied in the kit) into one of the suiting plates as shown and then insert through the front fixing holes of both units. 6.3.8 (B) Left hand unit: Slide the penny and lock washer on to the screw and secure using the M5 nut.
-
Page 15: Commisioning
6.4 COMMISSIONING 6.4.1 Open door ensuring drain valve is closed. 6.4.2 Ensure element is in horizontal position. 6.4.3 Fill pan with water to maximum level mark. 6.4.4 Switch on unit (on /off switch behind door). 6.4.5 Adjust operating thermostat to desired temperature. 6.4.6 This appliance is also provided with a terminal for connection of an external Equipotential conductor. -
Page 16: Door Removal
7.0 SERVICING DOOR REMOVAL 7.1.1 Remove door as shown. TEMPERATURE CONTROL & TAP REMOVAL... -
Page 17: Control Panel Removal
7.2.1 Remove as shown. 7.3 CONTROL PANEL REMOVAL 7.3.1 Remove as shown. SWITCH PANEL REMOVAL... -
Page 18: Operating & Safety Thermostat Removal
7.4.1 Remove as shown. OPERATING & SAFETY THERMOSTAT REMOVAL 7.5.1 Remove thermostats as shown. 7.6 ELEMENT COVER REMOVAL... -
Page 19: Element Removal
7.6.1 Remove as shown. 7.7 ELEMENT REMOVAL 7.7.1 Remove handle as shown. 7.7.2 Remove ring nut and safety switch as shown. -
Page 20: Tap Removal
7.7.3 Remove element as shown. 7.8 TAP REMOVAL 7.8.1 Remove as shown. Replace all parts in reverse order... -
Page 21: Accessories
8.0 ACCESSORIES BASKETS AND BASE PANEL 8.1.1 Left hand basket 1/6 8.1.2 Right hand basket 1/6 8.1.3 Basket 1/3 8.1.4 Perforated base panel... -
Page 22: Fault Finding
9.0 FAULT FINDING FAULT POSSIBLE CAUSES REMEDY Unit will not turn ON No Power to unit Check power supply is connected & turned ON Unit will not operate Unit not switched On Turn unit On inside door Unit will not switch On Element not in base off pan Make sure element in down position... -
Page 23: Service Information
11.0 SERVICE INFORMATION It is recommended to have a maintenance contract with a local service provider. SERVICELINE CONTACT: (UK only) Phone: +441438 363 000 Warranty Policy Shortlist For our warranty policy please go to www.falconfoodservice.com...
