Hotel function (only for the COMpact 5020 VoIP)
Automatic reception
Project numbers
X.31 on an internal S
The following functions, some of which are already
enabled, can be extended:
LCR (number of subscribers from 8 to 64)
LAN-TAPI (number of subscribers from 4 to 20)
Call data recording (number of datasets from 2000
to 6000)
Call Through (number of available lines from 1 to
all)
In addition, the following phone numbers can be
extended:
Subscriber numbers (number of subscribers from
32 to 64)
Maximum Extension
The COMpact 5020 VoIP can be operated with a
maximum of six external analogue and ISDN channels.
This means that in addition to the eight VoIP channels
possible, a maximum of 14 external channels are
possible.
Note: An S port corresponds to two ISDN channels.
0
The maximum number of individual ports and modules
each is indicated in the following table:
Ports/channels
External S ports
0
External analogue ports
Internal S ports
0
Internal U ports
P0
Internal analogue ports
VoIP channels (internal and
external)
Module
COMpact 2ISDN module
COMpact POTS module
COMpact 2POTS module
COMpact TSM module
COMpact 2VoIP module
COMpact 6VoIP module
Installation
The PBXs are intended to be operated in closed rooms. In
addition, all of the devices connected to the system must
be located in the building.
The PBXs enable you to connect some devices directly,
inasmuch as they are close enough to the PBX. The dis-
port
0
Max. num. in the COMpact
5020 VoIP 5010 VoIP
3 1
6 2
8 2
8 2
10 6
8 4
Max. num. in the COMpact
5020 VoIP 5010 VoIP
3 -
3 1
3 1
3 1
1 1
1 -
Important Information
tance depends on the length of the equipment connection
cables up to a maximum of 10 m.
If no suitable connection sockets are available or are too
far away, you must lay the installation cable permanently.
Warning: Power surges, which can occur during
electrical storms, can cause life-threatening electric
shocks
Lay all the cable inside the building – including the
cable to the door terminal system.
Note: Accessories and service parts can be bought in
specialised stores or in the Internet shop distriCOM at
http://www.districom.de. (Delivery is provided only in
Germany and Austria.)
Configuration/administration
The configuration manager on the PBX is contained in the
integrated web server and can be opened with a browser.
This prevents the need to install special programmes on
the computer. You need only an IP-supported operating
system and a compatible browser.
The configuration manager enables you to do the follo-
wing tasks:
Configure the PBX
Manage call data
Manage telephone book entries
Manage wake-up times
Manage call allowance accounts
Manage internal hold music/announcements
Manage data for Least Cost Routing
Service and maintenance
In order to limit the tasks the operator or user must per-
form, the configuration manager is divided according to
three authorisation levels:
Admin
Sub-Admin
User
Important: Make sure to take suitable measures for
protecting your data and yourself from misuse.
Prevent unauthorised access to the PBX and its
programming.
It is important to consistently use all of the avai-
lable options for assigning passwords.
Make use of the permissions available (program-
ming authorisation, exchange line authorisations,
restricted numbers, etc.).
Additional information about protecting the sys-
tem from misuse can be found at the German
Federal Office for Information Security: "Secure
use of digital telecommunication systems" in Ger-
man).
