Nav TV RGB-BNTv2 NTV-KIT903 Quick Start Manual

Backup camera interface

Advertisement

BHM
01/04/19
NTV-DOC336
3950 NW 120
th
Ave, Coral Springs, FL 33065 TEL 561-955-9770 FAX 561-955-9760
www.nav-tv.com
info@nav-tv.com
RGB-BNTv2
NTV-KIT903

Overview

The RGB-BNTv2 adds an aftermarket backup camera to the factory navigation screen in select
Bentley vehicles. A secondary video input is included on the RGB module and can be viewed at
any time by supplying power to an input wire (optional).

Kit Content

RGB Power Harness
NTV-HAR324
RGB Video
Harness
NTV-HAR331
RGB Converter
NTV-ASY254
Remote Control
NTV-REM004
1 |
P a g e
:
Agreement
End user agrees to use this product in compliance with all State and Federal laws. NAV-TV Corp. would not be held liable for
misuse of its product. If you do not agree, please discontinue use immediately and return product to place of purchase. This product is
intended for off-road use and passenger entertainment only.
