3950 NW 120
The S2P provides a 12v 'accessory' source
from multiple signal inputs. It can be
triggered in the following ways:
S2P Module
RCA male to male
NTV-ASY177
NTV-CON018
PIN #
Description
1
CAN HI
2
12v (+) Constant input
3
12v (+) OUT (when triggered)
4
Low voltage (+) input
5
CAN LO
6
Chassis Ground (-) input
7
RCA Video signal
8
Low voltage (-) input
:
Agreement
End user agrees to use this product in compliance with all State and Federal laws. NAV-TV Corp. would not be held liable for
misuse of its product. If you do not agree, please discontinue use immediately and return product to place of purchase. This product is
intended for off-road use and passenger entertainment only.
th
Ave, Coral Springs, FL 33065 TEL 561-955-9770 FAX 561-955-9760
www.nav-tv.com
S2P (Signal to Power)
NTV-KIT334
Overview
Kit Contents
RCA Splitter
NTV-CON013
S2P Pin out
Color
Brown/Red
Yellow
Red
White/Blue
Brown
Black
RCA
Blue
info@nav-tv.com
• From a video signal
• From CAN/GMLAN connection
• From low voltage input (Positive/Negative)
Wire side
BHM
05/20/14
NTV-DOC096
S2P Harness
NTV-HAR203
1 |
P a g e
