2 Technical data

2.1

Conditions of use

US parameters
Temperature
Humidity
Atmospheric pressure
EU parameters
Temperature
Humidity
Atmospheric pressure
2.2

Mechanical data

Parameters
Outer dimensions (siderails up)
Bed extension
Recommended mattress dimensions
Max. mattress height
Bed height
Backrest adjustment
Thigh rest adjustment
Lateral tilt
Trendelenburg / anti-Trendelenburg position
Siderail height (above mattress platform)
Weight /basic equipment/
Safe working load (SWL)
Max. lifting pole load
Project SERVICE MANUAL
Date 05-2017
Version
05
Values
Values
Values
215 x 105 cm / 84,65' x 41,34'
208 × 86 x 14 cm / 81,89' x 33,86' x 5,51'
44 – 82 cm / 17,32' x 32,28'
+50 °F — +104 °F
30 — 75 %
20,7 — 31,3 inHg
+10 °C — +40 °C
30 — 75 %
700 — 1060 hPa
0 – 22 cm / 0' – 8,66'
23 cm / 9,06'
70°
35°
+30°/-30°
+13°/-16°
45 cm / 17,72'
225 kg
250 kg
75 kg
