Instructions for Use
and Technical Description
AVE2
Birthing bed
D9U001PPB-0110
Version: 00
Date of publication: 2023-04

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AVE2 and is the answer not in the manual?

Questions and answers

Related Manuals for LINET AVE2

Summary of Contents for LINET AVE2

  • Page 1 Instructions for Use and Technical Description AVE2 Birthing bed D9U001PPB-0110 Version: 00 Date of publication: 2023-04...
  • Page 2 Service department: service@linetgroup.com AVE2 Birthing bed Author: L I N E T spol. s r.o. Related links: www.linet.com D9U001PPB-0110 Version: 00 Date of publication: 2023-04 Copyright © L I N E T, s.r.o., 2023 Translation © L I N E T, s.r.o., 2023 All rights reserved All trademarks and brands are the property of the appropriate owners.

  • Page 3: Table Of Contents

    Table of content Introduction ........... 5 8.6.2 Gynaecological position ..... 46 8.6.3 Foot rest position ........ 48 Safety and Dangers ......12 8.6.4 Maximum bed surface position... 50 Safety instructions ......12 8.6.5 Turning the leg rests sideways ... 51 8.6.6 Leg rest tray ajdustment .....
  • Page 4 11 Maintenance .......... 79 11.1 List of error, malfunction and generated messages ......79 11.2 Technical parameters ......80 11.3 Electrical parameters......81 11.4 Attached parts of product ....82 11.5 Transport instruction, Storage instruction ........... 82 11.6 Service and repairs ......83 12 Disposal ..........

  • Page 5: Introduction

    Please keep these instructions near the bed throughout its operation. Every person operating the birthing bed AVE2 must read and understand the contents of these instructions. Very important information is marked throughout the manual by the following symbols:...
  • Page 6 MAXIMUM PATIENT WEIGHT OVERALL PRODUCT WEIGHT BATTERY MARKING MANUFACTURER DATE OF PRODUCTION FOLLOW THE INSTRUCTIONS MANUAL SAFETY ISOLATING TRANSFORMER MEDICAL DEVICE INTERNAL USE THERMAL PROTECTION OF THE TRANSFORMER EQUIPOTENTIALITY PACKAGING MATERIAL: “KEEP DRY” PACKAGING MATERIAL: “FRAGILE!“ PACKAGING MATERIAL: “THIS SIDE UP” 6/89 D9U001PPB-0110...
  • Page 7 TEMPERATURE LIMITATION TRANSPORTATION MARKING: „RELATIVE AIR HUMIDITY“. TRANSPORTATION MARKING: “AIR PRESSURE”. MARKING ACCORDING TO THE DIRECTIVE EC 2002/96/EC (DIRECTIVE ON DISPOSAL OF OLD ELECTRIC AND ELECTRONIC APPLIANCES) SYMBOL FOR: “DO NOT DISPOSE OF THE PRODUCT INTO COMMUNAL WASTE. USE SPECIAL COLLECTION POINTS FOR OLD ELECTRONIC APPLIANCES"...
  • Page 8 WARNING: RISK OF LEG INJURIES WARNING: TRIPPING HAZARD WARNING: DO NOT PLACE OBJECTS ON THIS AREA DESIGNATION OF BIRTHING BED FOR ADULT USB CELL-PHONE RECHARGER MEDICAL DEVICE (COMPATIBLE WITH MEDICAL DEVICE REGULATION) UNIQUE DEVICE IDENTIFIER EAC MARKING CAUTION OR WARNING: THE POWER CABLE SHALL ALWAYS BE CLAMPED ON THE SELECTED PLACE OF THE BED USING A PLASTIC HOOK AS IS RECOMMENDED ON PICTURE!
  • Page 9 ABBREVIATION MEANING Light emitting diodes Power intake unit Information technology Personal computer Sound intensity unit Pressure unit Frequency unit in the SI system Electromagnetic compatibility High frequency Medical equipment CISPR International Special Committee on Radio Interference Working load limit D9U001PPB-0110 9/89...
  • Page 10 ACOUSTIC SIGNALLING SOUND MEANING One short acoustic signal when pressing Key lock activated a button The underfoot part is neither in the 'parked' nor Intermittent acoustic signal when pressing the in the 'active' position Trendelenburg button The battery charge is lower than 1/3 of its Intermittent acoustic signal when pressing the capacity positioning button...
  • Page 11 Production label – explanation of symbols The serial label contains information about Address of Manufacturer, Manufacturing Date (Year- Month-Day), Product Reference Number, Product Serial Number, Global Trade Item Number (GTIN), Unique Device Identification (UDI), symbols, weight specifications and electrical specifications Please address any potential queries to the authorized representative or directly to the Manufacturer L I N E T spol.

  • Page 12: Safety And Dangers

    1 Safety and Dangers CAUTION! Restricted Sale: In the USA, US Federal Law restricts this device to sale by or on the order of a licensed clinician Safety instructions ► Follow the instructions carefully ► Any non-observance of this manual may lead to injuries or material damage ►...
  • Page 13 ► Adjust bed height to approx. 20 cm below maximum height when transporting the bed in order to facilitate overcoming possible obstacles ► Do not exceed maximum load of 75 kg (165 lb) for mattress platform extension ► Ensure that the bed and its components are exclusively modified with the manufacturer´s approval ►...

  • Page 14: Un-Packing Manual

    2 UN-PACKING MANUAL Inspection of the consignment after delivery Do not unpack and/or accept the consignment if the package has any visual damage! If so, issue a complaint. Personal qualification The persons authorised for installation and putting into operation of the product, i.e. those trained by L I N E T spol.
  • Page 15 SEQUENCE OF INSTRUCTIONS Step 1 • Cut the pockets with the user guide to the bed open carefully and take them out. Then remove the box Step 2 • Cut the plastic bag open carefully; ideally around the bottom edge of the pallet and remove the polythene from the chair including the bottom of the box Step 3...
  • Page 16 Step 4 • Remove the other container from the pallet, so that the upper part is free Step 5 • Unscrew the medical chair (if it is included in the package). It is recommended to put the bed to a higher position. Step 6 •...
  • Page 17 Step 7 • Remove plastic plug from the locking element Step 8 • Remove the rest of the packaging material off the bed Step 9 • Make sure that all wheels are facing forward alongside the longer part of the pallet and lock the wheels to move in a straight line D9U001PPB-0110 17/89...
  • Page 18 Step 10 • Cut all plastic tapes that hold the basic frame onto the palette Step 11 • Put two polystyrene ramps to the edge of the pallet Step 12 • Carefully push the bed so that it gets from the anchoring wedges to the pallet and then move it down using the ramps 18/89...
  • Page 19 BACK-UP BATTERY CONNECTING WARNING! With regard to the possibility of unwanted switching on of AVE2 upon packaging, transport and unpacking, the battery is normally disconnected from the equipment. Only service technician approved by manufacturer performs this procedure. The following pictures show how to connect the battery: Step 1 •...
  • Page 20 Step 3 • Insert the connector in the back- up battery • Put the protective cover in place and screw the Allen wrenches back on Step 4 • Put the undercarriage cover back in place 20/89 D9U001PPB-0110...

  • Page 21: Overview Of Basic Parts

    3 Overview of basic parts 1. Back section 10. Side control panel 2. Seat section 11. Control light for power supply 3. Foot section 12. Holder for infusion stand 4. Castor, directional 1x 13. Hand grips 5. Castor with brake 3x 14.

  • Page 22: Overview Of Basic Versions

    Overview of basic versions PPB-AX Basic type Overview of colour versions Substituted by the letter “X”. Purple Blue Green Yellow Orange Safety Standards and specifications Referenced standards are listed in the Declaration of Conformity. The manufacturer has implemented certified quality management system in accordance with the following standards: ►...

  • Page 23: Function

    When using the delivery bed as part of the medical system, certain elements (medical devices) may interact. Before this application it is necessary to follow recommendations provided in the user manual of the delivery bed AVE2. General instructions Birthing Bed is intended for use in the Application Environment 5 (according to IEC 60601-2-52).

  • Page 24: Intended Use

    5 Intended use Birthing bed is designed to be used by mothers-to-be for vaginal delivery. The birthing bed is designed to enable different birthing positions in all delivery birthing stages including postpartum period. User population ► Pregnant women during ambulant and stationary pregnancy check-ups and/or in all labor stages and her companions.

  • Page 25: General Safety

    6 General safety CAUTION! Birthing Bed is not primarily intended for newborns. For this case there is a special cot which comes as a separate medical device. It is assumed that the position of the baby during breast-feeding is under the constant control of the mother and thus any uncontrollable movement of a newborn on the bed is improbable.

  • Page 26: Electromagnetic Compatibility

    ► Do not dismantle or execute unqualified repairs of motors, control unit, etc. ► The birthing bed AVE2 must not be used in medical facilities with fire or explosion risks caused by air or in combination with nitrous oxide and anesthetics or cleaning agents ►...

  • Page 27: Manufacturer Instructions - Electromagnetic Emissions

    6.1.1 Manufacturer instructions – electromagnetic emissions EMISSION TEST COMPLIANCE RF emissions Group 1 CISPR 11 RF emissions Class B CISPR 11 Harmonic emissions Class A IEC 61000-3-2 Voltage fluctuations / flicker emissions Complies IEC 61000-3-3 6.1.2 Manufacturer instructions – electromagnetic susceptibility IMMUNITY TESTS COMPLIANCE LEVEL Electrostatic discharge (ESD)
  • Page 28 TABLE 1 – IMMUNITY to RF wireless communications equipment TEST IMMUNITY BAND FREQUENCY SERVICE MODULATION TEST LEVEL (MHz) (MHz) (V/m) Pulse modulation 380 - 390 TETRA 400 18 Hz FM ± 5 kHz GMRS 460, 430 - 470 deviation FRS 460 1 kHz sine LTE band Pulse modulation...

  • Page 29: Mechanical Safety

    Mechanical safety CAUTION! No objects that may collide with the bed (furniture, stands etc.) may be located near it (20 cm minimum). Special caution must be taken when operating moving parts of the bed. Damage of the bed or patient injury may occur as result of the bed parts colliding with other objects! CAUTION! The bed is not designed for mothers over 240 kg (529 lb)

  • Page 30: Setting The Product

    7 Setting the product ► Check all delivered items after unpacking ► Install the equipment and accessories ► Install front panel (in case of tables with dismountable front panels) ► Always install the table on even floors ► When installing the table, avoid collision with power supply cable or excessive tensioning of the cable ►...

  • Page 31: Transport, Braking

    Transport, braking The birthing bed also allows for the transport of a patient. This is, however, subject to the following conditions: CAUTION! The birthing bed allows for the transport of a patient by pushing forward using the handle on the back section. Before transporting the patient, disconnect and store the power supply cables and equipotential and other connections properly, to prevent their tearing off.
  • Page 32 CAUTION! During transport, pay attention to the leg rests, side rails, foot section and hand grips to prevent hitting doors and other objects. Otherwise you can cause injury to persons or damage to the device. CAUTION! Observe the following security hints when transporting the bed: ►...

  • Page 33: Transport

    Transport DANGEROUS ELECTRIC VOLTAGE Before transport, disconnect power supply cables, equipotential and other connection lines, thus avoiding their pulling out DANGEROUS ELECTRIC VOLTAGE The power cable must be fixed to the bed at the selected point using plastic hook! Never wind up the cable on the bed/its parts, e.g. side handles, front section, handrails and other items! ...
  • Page 34 Suitable floor: ► Floor tiles ► Hard linoleum ► Cast floor Unsuitable floor: ► Too soft, not sealed or defective flooring ► Soft wood floor ► Soft and porous artificial stone floors ► Carpets with lining ► Soft linoleum ► When transporting the bed at a distance, check the castor control is active (main control lever) ►...

  • Page 35: Operating The Bed

    8 Operating the bed CAUTION! The birthing bed is not designed for permanent operation – motors can only be loaded up to the values defined on the label, i.e. 2 minutes of operation followed by 18 minutes of stand by. Excess workload of the device may result in automatic stop.

  • Page 36: Description Of The Control Panel For The Woman In Childbirth

    8.1.1 Description of the control panel for the woman in childbirth Lowering / lifting of back section Nurse Call 8.1.2 Adjustment of the handle in inactive position ► To initiate lowering, push the trigger in the marked direction with one hand, then lower the rail to the lowest position possible.

  • Page 37: Side Control Panel

    Side control panel CAUTION! Side control panel is located on both sides of AVE2 birthing bed. The panel can be operated by trained personnel only Holding the button initiates Nurse Call setting the bed to anti-shock position Stopping bed movement...

  • Page 38: Manual Setting Of The Cpr

    Manual setting of the CPR CAUTION! The CPR controller is marked with red information labels on both sides of the back section. The labels are marked with CPR text CAUTION! During movement, the back support must be loaded (e.g. with the patient's weight) NOTE Before the first use of the bed, we recommend performing the movement of the back rest of the bed multiple times using the CPR function.

  • Page 39: Electric Setting Of Trendelenburg

    Electric setting of Trendelenburg CAUTION! The controller is marked with orange on both sides of the back section. CAUTION! If the bed stops during the positioning movement and the control box generates a sound signal, the foot section has not been fixed properly. For positioning of the back section: ►...

  • Page 40: Setting Of The Foot Section

    Setting of the foot section CAUTION! The load capacity of foot section is 150 kg (330 lb) maximum CAUTION! The load capacity of foot section and leg rests together is 170 kg (374 lb) maximum CAUTION! Do not overload the footrest due to the unsecured position. It is necessary to always secure the part in the end positions (parking, active)! CAUTION! Foot section positioning (sliding in/out, lifting/lowering, inclination) always...

  • Page 41: Folding/Unfolding

    8.5.1 Folding/unfolding CAUTION! Before folding, always make sure the foot section is in the lowest position and back section is not in Trendelenburg position CAUTION! In case of putting aside the upholstery of the foot section from the bed, it must be placed on its wide laying surface on flat surface such as ground or bed.

  • Page 42: Lifting/Lowering

    8.5.2 Lifting/lowering The surface of the completely pulled out foot section may be lifted up to the level of the seat. All listed positions of the foot section do not limit motoric setting of the birthing bed. Before loading the foot section, its correct locking should be checked by short moves to the sides.

  • Page 43: Tilting Up/Down

    8.5.3 Tilting up/down ► Pull the control lever with the right hand ► Then push the foot section downwards ► You can lock the foot section in any position by releasing the control leve ► Uninterrupted push downwards results in low horizontal position of the foot section D9U001PPB-0110 43/89...

  • Page 44: Adjusting The Leg Rests

    Adjusting the leg rests CAUTION! The load capacity of one leg rest is 70 kg (154 lb) maximum CAUTION! The load capacity of foot section and leg rests together is 170 kg (374 lb) maximum CAUTION! Always brake the footrests plates before transport! This means to set up the lowest height level and turn them in a way that their edges do not overlap the edges of the footrests CAUTION!

  • Page 45: Leg Straps

    8.6.1 Leg straps Fixing straps for legs are integral part of each foot rest to enable better support of flaccid mus- cles of the mother-to-be during the stages of birth ► Loosen the strap (1) ► Place the mother’s-to-be calf comfortably in the bowl of the foot rest (2) ►...

  • Page 46: Gynaecological Position

    8.6.2 Gynaecological position For positioning: ► Pull „Turning the leg rest sideways“ control lever ► and with same hand pull the leg rest in the desired position ► Then pull the „Tilting of the leg rest“control lever as on the picture below 46/89 D9U001PPB-0110...
  • Page 47 ► and with same hand pull the leg rest in the desired position Then adjust the leg rest tray: ► With one hand pull the „Folding/unfolding of the leg rest tray“control lever as on the picture below (1) ► Then with same hand pull the tray to the desired position (2) ►...

  • Page 48: Foot Rest Position

    8.6.3 Foot rest position The leg rests can be adjusted in the Foot rest position. For positioning: ► Pull „Turning the leg rest sideways“ control lever ► and with same hand pull the leg rest in the desired position ► Then pull the „Tilting of the leg rest“control lever 48/89...
  • Page 49 ► and with same hand pull the leg rest in the desired position D9U001PPB-0110 49/89...

  • Page 50: Maximum Bed Surface Position

    8.6.4 Maximum bed surface position The leg rests can be positioned horizontally along the sides of the foot section. Due to this function, one laying surface can be achieved together with the seat and back sections. For positioning ► Pull „Turning the leg rest sideways“...

  • Page 51: Turning The Leg Rests Sideways

    8.6.5 Turning the leg rests sideways The leg rests can be turned sideways better access to a birth mother. For turning the leg rest sideways: ► Pull the control lever ► Then pull the leg rest to the desired position ►...

  • Page 52: Leg Rest Tray Ajdustment

    8.6.6 Leg rest tray ajdustment CAUTION! Make sure that the footrest cups are handled correctly. Improper use of the footrests will damage the footrest upholstery Leg rest tray can be individually turned sideways according to the physical proportions of the birth mother. To do so, the leg rest must be in "Gynaecological position".

  • Page 53: Leg Rest Tray Height Adjustment

    8.6.7 Leg rest tray height adjustment Leg rest tray can be in- dividually adjusted ac- cording to the physical proportions of the birth mother. To do so, the leg rest must be in "Gy- naecological position". ► Then with one hand pull the control lever ►...

  • Page 54: Backup Battery

    Backup Battery WARNING! The batteries may be only replaced by the appropriate service personnel! WARNING The battery is intended solely for emergency power supply during power failures. WARNING In case that the insufficiently trained personnel will perform the replacement of battery, the danger situation may occur or the functionality of medical device may be reduced.

  • Page 55: Grab Handles, Detachable (R/L)

    ► l Battery status indicator: ► Light on: battery disconnected or defective ► Flashing: charging the battery ► Light off: charging completed Grab handles, detachable (R/L) WARNING! When simultaneously using hand grips and setting the leg rests to the Foot rest position, collision may occur! Hence, it is necessary to pay attention to avoid injury of the personnel and/or the mother in labor when adjusting the leg rests WARNING!

  • Page 56: Holder Of Infusion Stand

    Holder of infusion stand Double-way undetachable infusion holder is used to fix the infusion stand. 8.10 Equipotential coupling The delivery bed is fitted with a coupling for synchronizing the potential with other electrical medical equipment. The coupling is located behind the bed under the lying surface of the bed. The bed is interconnected to the other device by means of a cable (not supplied with the bed) that is connected easily by its end to the coupling 8.11 Exchangeability of the upholstery...

  • Page 57: Nurse Call

    8.12 Nurse call CAUTION! The control elements of the nurse call function cannot be deactivated! CAUTION! If the power supply of the bed is disconnected, the Nurse Call function can work for about 1 or 2 months (if the bed positioning is not used) The nurse call button is located on the inner side of the side handle control panel (on the side of the la-...

  • Page 58: Backlighting Of The Birthing Bed

    8.13 Backlighting of the birthing bed ► The backlighting is turned ON by short pressing the button on the side control panel of the birthing bed ► Repeated push of the button switches the backlighting OFF Backlight is controlled by the personnel only. 8.14 Eurolath along the seat section CAUTION! Ensure that when the chair moves up and down, the surrounding objects do not...

  • Page 59: Rear Bed-Head

    8.15 Rear bed-head CAUTION! To allow the anesthesiologist better access to the head of a birth mother, always remove the bed-head! CAUTION! Never use the rear bed-head to manipulate the birthing bed during its transport! Rear bed-head represents a safety element of the bed and can be used by the birth mother as a handle.

  • Page 60: Front Holder With Protective Elements

    8.17 Front holder with protective elements CAUTION! Maximum weight capacity is 70 kg (154 lb) Accessories can be attached to the holder and it serves as foot section protection as well. The set contains two side bumpers. 8.18 Bowl The bowl is made of stainless steel, with the capacity of 8 liters.

  • Page 61: Accessories

    9 Accessories Cable hand controller CAUTION! For safety reasons it is restricted to pass the hand controller cable under the birthing bed to reach the other side! The operator may use the hand controller buttons to set the height Power supply indicator position of the seat and back sec- tion inclination.

  • Page 62: Supporting Bar

    Supporting bar CAUTION! Maximum weight load of the supporting bar is 70 kg (154 lb) in all direction. Supporting bar is vertically locked up, it may be ejected from the holder in the upward direction! ► After having pulled out the cross-bar, it is necessary to drag both arresting elements to unlock them Infusion stand, stainless steel, telescopic CAUTION! Max.

  • Page 63: Doctor's Chair (Ergonomic)

    Doctor's chair (ergonomic) Doctor’s chair D9U001PPB-0110 63/89...

  • Page 64: Upper Mattress (For 5.12 Inch Cushioning)

    Upper mattress (for 5.12 inch cushioning) The accessory is primarily used after post-partum; it increases the comfort of the resting mother. Front bumper fitted on the leg rest (R/L) CAUTION! Always park the leg holder trays before transport! Adjust the lowest position and move so that they do not overlap the contour of the leg rest Intended for hanging the ac- cessories and, at the same...

  • Page 65: Protractor Of The Seat Part, Protractor Of The Back Part

    Protractor of the seat part, Protractor of the back part CAUTION! The protractor is only for information! It is used to inform about the inclination of the back or the seat part of the delivery bed. 9.10 Bracket for oxygen bottles CAUTION! Maximum load 10 kg (22 lb)! CAUTION!
  • Page 66 CAUTION! Before actively using the oxygen bottle holder, always check the correct dimensions of the oxygen cylinder, including the top of the bottle. Larger dimensions can collide with positioning bars! CAUTION! When positioning the seat, the oxygen bottle holder also becomes mobile CAUTION! When using an oxygen cylinder, always check the patient's movements on the bed.

  • Page 67: Patient Card

    9.11 Patient card CAUTION! Condition of the order including the front bumper of the leg rest CAUTION! Snap only to the front bumper on the leg rest! CAUTION! If the patient's card is hung in other places, such as the bed side or the headboard, there is a risk of instability.
  • Page 68 WARNING! It is absolutely forbidden to see staff moving away from the baby plate when the new-born is lying there! CAUTION! The Baby plate can only be used by staff trained for this! WARNING! When mounting the baby plate on the bracket and after hearing the click, check by pulling towards you that the baby plate is correctly insured! The safety lever must be in the down position (safety position) CAUTION!
  • Page 69 The baby plate is used to drop the new-born for a short period of time. The umbilical cord is cut when the new-born is placed on the baby plate and then placed on the breast of his mother, or on another table to perform some necessary procedures.

  • Page 70: Usb Cell-Phone Recharger

    9.13 USB cell-phone recharger WARNING! Risk of injury due to improper use! ► Make sure that the accessories attached to the USB connector are intact. The user of the bed is responsible for meeting this requirement WARNING! Risk of injury due to pinched power cord! ►...

  • Page 71: Care

    10 Care All L I N E T spol. s r.o. products are designed for many years of service under the conditions of correct use. Please use your bed and its accessories carefully. Please follow these instructions for use and recommended operation and maintenance instructions. Avoid negligent handling.

  • Page 72: Cleaning The Bed

    According to the principles of good hygienic practice, the cleaning and disinfection of the delivery room, its equipment and all the medical devices used, must be made directly and promptly after the delivery (birth) in order to prepare the equipment for a new delivery. These principles apply also to the cleaning and disinfection of the delivery bed.
  • Page 73 Bed frame / supporting structure - completely from the head rest part to the sitting part Lift the chassis to the highest position, pull out the mains plug - remove the protective parts (right and left) and put them back in the original position after cleaning Lift the right chassis plastic cover and clean dirty areas 10.
  • Page 74 12. Collecting tray (can be cleaned thermally, as stainless steel) 13. Castors and brake pedals 74/89 D9U001PPB-0110...

  • Page 75: Recommended Disinfection (Disinfectants For Wiping)

    10.1.2 Recommended disinfection (disinfectants for wiping) WARNING! Do not use disinfectants with active substance: alcohol over 30%, active chlorine, iodine, aldehydes RTU- Ready-to-use non-diluted products - spray or foam Active substance How to use Example of disinfectant Amine, Alcohol up to 30% Spray and wipe Incidin foam Hydrogen Peroxide...

  • Page 76: How To Properly Coat Bed With Hospital Bedding

    10.1.3 How to properly coat bed with hospital bedding The delivery bed must be protected against excessive dirt by a fabric covering! One of the options is using a covering from the operating room, the size of which corresponds to that of the relevant de- livery bed section, or with a fabric coating used for standard beds.

  • Page 77: How To Properly Coat Bed With Disposable Bed Sheets

    10.1.4 How to properly coat bed with Disposable bed sheets Special-shape disposable coating materials, designed specifically for AVE2 birthing bed, can also be used: ► Swing out the back section of the mattress and put the coating on it ► Then return the back section to its place ►...

  • Page 78: How To Properly Coat Bed With Terrycloth

    10.1.5 How to properly coat bed with terrycloth You can also use special-shape terrycloth set directly onto AVE2 birthing bed: ► Swing out the seat section of the mattress and put the coating on it ► Return the seat section to its place and lift the back section ►...

  • Page 79: Maintenance

    11 Maintenance CAUTION! From practical testing results, the technical lifetime of the product is 15 years. Lifetime of the battery is limited and must be replaced. ► Batteries (these are provided with the warranty of 6 months) ► Gas springs need to be replaced every 12 years ►...

  • Page 80: Technical Parameters

    11.2 Technical parameters Total length of the lying area 2 122 mm (83.54 inch) (including the foot section) Minimum length in the default setting 1 570 mm (61.81inch) (without the foot section) Full width with the side rails in active position 980 mm (38.58 inch) Full width with the side rails in parked position 960 mm (37.79 inch)

  • Page 81: Electrical Parameters

    Permitted back section load (125 mm from the edge) 150 kg (330 lb) Permitted foot section load (125 mm from the edge) 150 kg (330 lb) Permitted leg rest load 70 kg (154 lb) Permitted load of side rail 75 kg (165 lb) vertical press Permitted load of supporting bar 70 kg (154 lb) Weight of mattress...

  • Page 82: Attached Parts Of Product

    11.4 Attached parts of product The attached parts on the product are classified as Type B - they provide basic protection of the patient and comply with the applicable requirements of ČSN EN 60601-1 ed. 2:2007, by which they meet the requirements on classification of Type B attached parts. 11.5 Transport instruction, Storage instruction Operation 10°C –...

  • Page 83: Service And Repairs

    11.6 Service and repairs CAUTION! All service revisions, safety and technical inspections or service interventions must be executed only by a technician trained by L I N E T spol. s r.o. company ► Diagrams, lists of product parts, descriptions or other information intended to help the service personnel with the repair of product parts, repairable by the service personnel only as implied by the manufacturer, are available upon demand at the manufacturer.

  • Page 84: Disposal

    12 Disposal 12.1 Environmental protection L I N E T spol. s r.o. is aware of the important role that the protection of our environment plays for future generations. The materials of this product are environmentally compatible. It does not contain hazardous sub- stances on the basis of cadmium, mercury, asbestos, PCB or CFC.

  • Page 85: List Of Available Equipment

    13 List of available equipment N (BASIC VERSIONS) PPB-AX Birthing bed AVE2: Standard leg rests + leg straps (pair) Backup battery Sliding foot section including the upholstery Seamless mattress Manual CPR Infusion stand holder on both sides of the bed...
  • Page 86 N (MATTRESS THICKNESS): PPB-080-X 130 mm (5.12 in) PPB-081-X 130 mm (5.12 in) with a zipper PPB-101-1000-100 DUOCOAT MATTRESS COMFORT- SET PPB-101-2000-200 DUOCOAT MATTRESS PREMIUM - SET A (COLOR): Violet F4340-50621 Blue F4340_07459 Green F4340-20157 Yellow F4340_07477 Orange F4340_20127 Own choice of leatherette F4340_00002 F4340_07422 F4340_07432...
  • Page 87 A (COLOR): F4340-50619 F4340-50620 F4340-50622 F4340-50623 Pink F4340-20149 N (UPHOLSTERY): PPB-006.07-X Upholstery of the footrest PPB-382.03-X Upholstery of the right leg holder PPB-382.04-X Upholstery of the left leg holder PPB-110 Leg upholstery for COMFORT and PREMIUM mattress N (NURSE CALL) SB-PPB-353-01 Nurse Call SB-PPB-353-02...
  • Page 88 N (OPERATIONAL MANUALS) 84660 PPB-072-CZ 84664 PPB-072-DE 84666 PPB-072-EN 84668 PPB-072-ES 84670 PPB-072-FR 84672 PPB-072-IT 84678 PPB-072-SWE 87892 PPB-073-US 87795 PPB-072-NL 87894 PPB-073-CAN N (OPTIONAL) PPB-069 Front holder of accessories GKB-076.X Doctor´s chair - ergonomic PPA-36 Telescopic infusion stand ZK-05.X Doctor´s chair PPA-33 Large stainless steel bowl - 10 l...

  • Page 89: Warranty

    N (SELECTION OF CASTORS) PPB-478 Standard castors (5,91 in) PPB-479 Castors with longer pin (5,91 in) 14 Warranty L I N E T spol. s r.o. will only be held responsible for the safety and reliability of products that are regularly serviced and used in accordance with the safety guidelines.
