Albatros / Super-Albatros
2
1
3
22

Working width adjustment

After the basic adjustment, (traction point, first
furrow width) the desired working width may be set
with the turnbuckle or ram (6/3);
Hydraulic system: in small steps during motion.
Traction point and first furrow working width are
adapted automatically.
Turnbuckle/cylinder longer – smaller working width
Turnbuckle/cylinder shorter – wider working width
6

Levelling bars

1
(if available, 11/1)
Set all equally; not too deep, so that they do not
„stand" in the turned soil.
11
05.2013
Subject to technical modifications
