THEATRE COLOUR LT
PR-3021
This product manual contains important information about the safe installation and
use of this projector. Please read and follow these instructions carefully and keep this
manual in a safe place for future reference.
PR LIGHTING LTD.
Yingbin Road, Dashi Panyu, Guangzhou, 511430 China
h t t p : / / w w w . p r- l i g h t i n g . c o m
Advertisement
Table of Contents
Related Manuals for PR Lighting THEATRE COLOUR LT
Summary of Contents for PR Lighting THEATRE COLOUR LT
- Page 1 THEATRE COLOUR LT PR-3021 This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. PR LIGHTING LTD.
- Page 2 Please read and follow these instructions carefully and keep this manual in a safe place for future reference. The Theatre Colour LT is an innovative projector with an elegant housing made from high quality aluminium-alloy with an epoxy paint finish. The product complies to CE norms and standards and uses international protocol DMX 512.
-
Page 3: Safe Usage Of The Projector
Always disconnect from the mains, when the device is not in use or before cleaning it or before attempting any maintenance work. If you have any questions, don’ t hesitate to consult your dealer or manufacturer. 3/12 Theatre Colour LT manual.doc... -
Page 4: Installing The Projector
The projector should be switched on with the shutter open and the beam focused to do this. Note: the three screws will only need a small adjustment to centre the lamp, do not try to unscrew them completely. 4/12 Theatre Colour LT manual.doc... -
Page 5: Power Supply - Mains
“ y” , then the setting has been enabled. In the same way, if it was showing “ n” when you pressed ENTER the option has been disabled. The Red LED will flash during this operation. 5/12 Theatre Colour LT manual.doc... -
Page 6: Setup Options
Note, care should be taken to ensure that none of the connections touch the body of the plug or each other. The body of the plug is not connected in any way. The Theatre Colour LT accepts digital control signals in standard DMX512 (1990) format. -
Page 7: Dmx Terminator
“ listen” to the digital control information being sent out from the controller. The Theatre Colour LT has 9 channels, so set the No. 1 projector’ s address 001, No. 2 projector’ s address 004, No. 3 projector’ s address 007, No. 4 projector’ s address 010, and so on. -
Page 8: Dmx Control Channel Functions
DMX CONTROL CHANNEL FUNCTIONS The Theatre Colour LT uses 3 standard DMX 512 channels. They are listed in the following table. CHANNEL DMX512 VALUE DESCRIPTION 0-43 Blackout 44-87 White COLOUR 88-131 Yellow WHEEL 1 132-175 Blue 176-219 Orange 220-255 Light green... -
Page 9: Troubleshooting
32000 8000 3555 2000 1280 11° (lux) 92000 23000 10222 5750 3680 2500 1877 1437 1135 DISTANCE(m) 12.5 17.5 22.5 11° DIAMETER(m) 0.48 0.96 1.44 1.92 2.88 3.37 3.85 20° DIAMETER(m) 0.88 1.76 2.46 6.17 9/12 Theatre Colour LT manual.doc... -
Page 10: Electrical Diagram
AC 12.5V/45W SENSOR THERMOSTAT DIMMER PCB FAN2 FAN1 LAMP 230V/1200W FAN3 FAN4 COLOUR COLOUR WHEEL 1 WHEEL 2 FUSE 4A/250V MAIN PCB White Black DMX512 DMX512 DMX512 OUTPUT INPUT LED2 LED1 16 PIN DISPLAY PCB 10/12 Theatre Colour LT manual.doc... -
Page 11: Component Order Codes
230040087 WATCH DOG CHIP 170050002 ARITHMETIC AMPLIFIER CHIP 230040126 MICROPROCESSOR 1 230040127 MICROPROCESSOR 2 170040032 EEPROM CHIP 170170039 STABLE-POWER CHIP 170170034 RESET CHIP 170040002 TTL REVERSION CHIP 170170012 BUS CHIP FOR RECEIVING/TRANSMITTING 230040093 DIGITAL-SCREEN CHIP 11/12 Theatre Colour LT manual.doc... - Page 12 PR LIGHTING LTD. Yingbin Road, Dashi, Panyu, Guangzhou, China Post-Code: 511430 TEL: 020-8478-1888 FAX: 020-8478-6023 P/N: 321010056 Last Revision: 16:01:2004 12/12 Theatre Colour LT manual.doc...
