Handlebar Assembly - LifeSpan Stretch Partner Assembly Instructions

CONTENTS:
STEP 1:
• Base
FRAME ASSEMBLY
• Handlebar post
• Seat Frame
a. Insert the handlebar post bracket into
• Handlebars & Safety Straps
the end of the base frame.
• Seat Bottom
b. Align the holes and using four, 5mm
• Seat Back
Allen head screws and 4 Bent Washers,
• Pedal Axle
hand tighten all four screws before
• Pedals
securely tightening them with the Allen
• Seat Pivot Axle
wrench provided.
• Instruction Bracket with
User Instructions
• Plastic Covers
Push base onto bracket. Securely
• Hardware Bag/Tools
a. 8 - 5mm Frame Screws
b. 8 - Bent Washers
c. 1 - 5mm Allen Wrench
d. 1 - 4mm Allen Wrench
e. 2 - 14mm Wrench's
f. 1 - Phillips Screwdriver
g. 1 - 14mm Lock Nut
h. 1 - Straight Washer
STEP 5:
SEAT ASSEMBLY
a. Locate the seat bottom, remove the four screws from the back of the seat
bottom and securely tighten all four screws on the seat frame as shown in
diagram below.
b. Locate the seat back, remove the four screws from the seat back and
securely tighten all four screws onto the seat frame bracket.
Note: Turn the seat bottom so that the front of the seat is flush with the oval seat tube. It
should not overhang past the seat tube.
Turn the seat
bottom so the
front of the seat
is flush with the
seat tube.
STEP 2:
PLASTIC COVERS
a. Remove the three Phillips head screws
already in place on the plastic covers.
b. Place the 2 plastic halves in place over
the front joint and tighten down the 3
Phillips head screws.
tighten four 5mm Allen head
screws with bent washers.
STEP 6:
PEDAL AXLE/PEDALS
a. Locate the pedal axle and the foot pedal. One of the ends on the axle already has a nut and washer installed.
Over the opposite end, slide the left side pedal.
b. Push the axle through the pedal axle shaft and push the right pedal over the end.
c. Secure the pedal in place by using a washer and locknut. To tighten the nut you will need to use the 2 - 14mm socket
wrenches provided. Put one wrench on each end of the axle and turn clockwise until tight.
d. After the axle nuts are tightened, push the axle caps into the pedals.
STEP 3:

HANDLEBAR ASSEMBLY

a. Put the Safety Strap around the
handlebars and push the handlebar
down onto the handlebar post.
b. Locate the Instruction bracket and align
the screw hole in the bracket with the
screw hole in the front of the handlebar
post. Hand tighten a 5mm Allen head
screw with Bent Washer.
Tighten down three
Phillips head screws.
c. Hand tighten the remaining 3 screws
with bent washers and then securely
tighten all four screws with the 5 mm
Allen wrench provided.
Over handlebar
Use a socket wrench on each
Put the right pedal on the axle
end to tighten the axle nuts.
and insert through shaft.
STEP 4:
SEAT AXLE ASSEMBLY
a. Locate the seat frame assembly and the seat pivot axle. Place the
seat frame in place over the frame bracket and align the hole in
the frame with the hole at the back of the seat frame.
b. Once the holes are aligned, insert the axle into the bracket. MAKE
SURE THAT THE INDENT IN THE AXLE LINES UP WITH HOLE IN
THE BRACKET AS SHOWN IN THE PHOTOGRAPH BELOW.
c. Using the 4mm Allen wrench provided, tighten the 2 set screws as
shown in the picture below.
Below handlebar
Push the axle into the bracket
and make sure the indent in the
axle is aligned with the hole in
the frame bracket.
Push on pedal cap.
Using the 4mm Allen Wrench,
securely tighten both set screws
on the seat pivot axle.
MONTHLY
MAINTENANCE
• Check all screws in the
frame and seat making
sure that they are tight
and secure.
• Check Safety Strap.
If showing wear, call
PCE Fitness for
replacement.
• Check rubber bumper
in the handlebar pivot.
If any cracks or wear
exists, replace the
rubber bumper.
• Inspect the seat pivot
axle and set screws
ensuring that the axle
is properly centered
and the set screws
are tight.
