Installation Instructions
Assembly View
Page 1 of 10
Installation Instructions
Playworld Systems
PlayForm 7
Father To Mother Belts And Handle
Installation Preparation
Recommended Crew: ........................... Two (2) adults
Installation Time: ................................... 6 man-hours
Use Zone: .............................................. Refer to the layout drawing
User Group Age (years): ....................... ASTM/CSA: 5-12, EN: 6-14
ICON KEY
Fully Tighten
Hardware
Do Not Fully Tighten
Hardware
Drill
Hammer
Model XX0705
®
Add 1 Drop of
Thread Locking Adhesive
Pour Concrete
Dig Footing Holes
Critical Fall Height
Model XX0705
PA1361
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Playworld Systems PlayForm 7 XX0705
Summary of Contents for Playworld Systems PlayForm 7 XX0705
- Page 1 Installation Instructions Installation Instructions Playworld Systems Model XX0705 ® PlayForm 7 Father To Mother Belts And Handle Installation Preparation Recommended Crew: ......Two (2) adults Installation Time: ........6 man-hours Use Zone: ..........Refer to the layout drawing User Group Age (years): ....... ASTM/CSA: 5-12, EN: 6-14...
-
Page 2: Installation Instructions
Installation Instructions Follow the details in alphabetical order. For clarifi cation, each detail references the step description. The step descriptions start on page 7. Note: Curved side of the casting should face toward the frame. Cover Casting AAU0840 (10 Total) Hardware and parts shown in Italics are supplied with the... - Page 3 Installation Instructions Align the holes in the belt with those in the bottom of the frame bracket. 3/8" Flat Washer BAE0595 (40 Total) Bottom Plate APL2275 (10 Total) 3/8" x 1-1/4" Button Head Bolt BAE0666 (40 Total) Detail A-3 3/8" x 1-1/2" Step 3 Button Head Bolt Attach each end of the belt to the underside of...
- Page 4 Installation Instructions Belt Handle AAU0834 (10 Total) 1/4" x 1/2" Button Head Bolt BAE01521 3/8" x 1-1/2" (20 Total) Button Head Bolt BAE06645 (20 Total) 3/8" Flat Washer 1/4" Button Head Nut BAE0595 BAE0161 (20 Total) (20 Total) Detail A-5 Detail B Step 3 Step 4...
- Page 5 Installation Instructions Note: this end of the rope will connect to the Father Father To frame. Mother Rope AMC0717 (1 Total) Note: this end of the Remove the frox balls from rope will connect to the the ends of the rope. Balls are Mother frame.
- Page 6 Installation Instructions 3/8" Flat Washer BAE0595 (8 Total) 3/8" x 3/4" Button Head Bolt BAE0659 (8 Total) Father To Mother Rope See Reference below for placement. Detail D Step 6 Attach the Father to Mother rope to the Father and Mother frames. Mother Frame Father To Mother Rope...
- Page 7 Installation Instructions Notes Before You Begin: Do not over tighten bolts during assembly, only snug Step 6: Attach the Father to Mother rope to the Father and Mother frames. See tighten them until assembly is complete. Detail D and Rope Placement Reference. Position the rope castings against the Father and Mother frames, apply a drop of thread locking adhesive to the Carefully read and understand these installation instructions before you bolt threads and attach as shown.
-
Page 8: Bill Of Materials
Bill of Materials Installation Instructions XX0705 - PLAYFORM 7 FATHER TO MOTHER BELTS AND HANDLE PART NO. DESCRIPTION QTY. AAU0834 BELT HANDLE AMC0686 BELT - MOTHER TO FATHER - MIDDLE AMC0687 BELT - FATHER TO MOTHER - SECOND AMC0688 BELT - FATHER TO MOTHER - OUTER AMC0717 ROPE - .63"... - Page 9 Installation Instructions Equipment Maintenance Playworld Systems ® Fasteners • Inspect for loose fasteners. Model XX0705 Tightening torque specifi cations are: Bolts and Nuts: Snug tighten and tighten an additional PlayForm 7 one-half turn. Father To Mother Belts And Handle • If during the maintenance process a bolt needs to be...
-
Page 10: Inspection Checklist
Inspection Form Installation Instructions Preventive Maintenance • Be sure that you are using a copy of this Inspection Form and not your original..for Safety's Sake! • Use the Inspection Codes listed below and record condition of equipment at time of examination on the Inspection Checklist.
