SPARE PARTS
C-00180-179
Planetary Diff. Gears - Steel -
1 Set
C-00180-188
O-Ring - Silicone - 4x8mm -
5 pcs
C-00180-193
Drive Shaft - Centre - Front -
Steel - 1 pc
C-00180-207
Steering Block Arms -
Aluminium - 2 pcs
C-00180-226-B
Wing - Composite - 1 pc
C-00180-242
Side Guards - Left-Right - Com-
posite - 1 Set
C-00180-293
Ball 6.8mm - Steel - 4 pcs
20
C-00180-182 C-00180-183
O-Ring - Silicone - 5x8mm - Diff. Gasket - 4 pcs
5 pcs
C-00180-189 C-00180-190
Shock Bladders - Silicone - Shock Washer - 2.5x6x0.5mm -
4 pcs Steel - 10 pcs
C-00180-197 C-00180-204
Anti-Roll Bar - 2.4mm - Front Shim Rings - 6x18x0.2mm -
- 1 pc Steel - 10 pcs
C-00180-216 C-00180-219
Servo Saver Spring - 1 pc Suspension Arm Pivot Pin -
Upper - Front - Steel - 2 pcs
C-00180-230 C-00180-231
Wheel Nut - Aluminium - Collar - for Anti-roll Bar - Alu-
Ribbed - 4 pcs minium - 1 pc
C-00180-246 C-00180-251
Anti-Roll Bar - 2.6mm - Rear Wing Washer - Composite. -
- 1 pc 2 pcs
C-00180-301 C-00180-305
Centre Roll Cage Mount - Com- Centre Roll Cage Pin - Steel -
posite - 1 Set 2 pcs
C-00180-184 C-00180-186
Gear Diff. Pin - Steel - 2 pcs Chassis Brace Link - Steel - 1 pc
C-00180-191 C-00180-192
O-Ring - Silicone - 9x12mm O-Ring - Silicone -
- 5 pcs 16.2x19.8mm - 5 pcs
C-00180-205 C-00180-206
Diff. Outdrive Pin - 2x10mm - Steering Rack Bushing - Steel
Steel - 4 pcs - 2 pcs
C-00180-220 C-00180-223
Ball End 5.8mm - for Anti Roll Centre Drive Shaft - Truggy -
Bar - Steel - 4 pcs Rear - Steel - 1 pc
C-00180-238 C-00180-240
Suspension Arm Mount - Rear - Suspension Arm Mount - Front -
Aluminium - 1 set Aluminium - 1 Set
C-00180-287 C-00180-290
Shock Spring - Medium - Rear Shock Spring - Medium - Front
- 2 pcs - 2 pcs
C-00180-316
C-00180-322
Shock Cap - Lower - Aluminium
Suspension Arm Pivot Pin - Low-
- 2 pcs
er Inner - Fr/Re - Steel - 2 pcs
