Team Corally SSX8X Instruction Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
CHECK FOR THE LATEST
VERSION OF THIS
INSTRUCTION MANUAL
2018-V2

Advertisement

loading

Related Manuals for Team Corally SSX8X

Summary of Contents for Team Corally SSX8X

  • Page 1 CHECK FOR THE LATEST VERSION OF THIS INSTRUCTION MANUAL 2018-V2...
  • Page 2 RECOMMENDED ACCESSORIES STAY To obtain the maximum performance out of your SSX-8 we recommend the following accessories TUNED... "CS 4014" SERVO DYNOSPEED HIGH SPEED - VELOX 805 HIGH V0L TAGE SERV0 C-61302 • Low Profile Servo • Ultra High Speed 1950 KV •...
  • Page 3 RECOMMENDED ACCESSORIES & TOOLS Hex Drivers Nut Drivers VOL TAX 120C HV Aluminium handle • Hardened tool tip Aluminium handle • Hardened tool tip For M3 Nut For M4 Nut C-16161 Factory Pro Tool - Nut Driver 5.5 mm C-16162 Factory Pro Tool - Nut Driver 7.0 mm Voltax 120C LiPo Battery C-49523...
  • Page 4 10 15 REAR SUSPENSION ASSEMBLY C-13094 Apply CORALLY LOCK-IT 100 SOFT C-00130-024 Rear Bulkhead Right C-00130-023 Rear Bulkhead Left C-00130-009 Motor Pod Stiffener C-00130-089 Carbon Chassis C-30062 Flat Head Screws M4x10 (6pcs) Socket Head Screw Button Head Screw Flat Head Screw...
  • Page 5 10 15 REAR SUSPENSION ASSEMBLY C-00130-029 Ball Bearing Inserts (2pcs) C-361221 Ball Bearing 12x21x5 (2pcs)
  • Page 6 10 15 REAR SUSPENSION ASSEMBLY C-00130-025 Rear Axle Shaft C-00130-056 Aluminum Shim Ring ø12x16x1.0 C-00130-050 32T Pulley Washer C-00130-026 RED MARKING Steel Pin 3x20 Socket Head Screw Button Head Screw Flat Head Screw...
  • Page 7 10 15 REAR SUSPENSION ASSEMBLY C-00130-020 Wheel Spacer Rear...
  • Page 8 10 15 REAR SUSPENSION ASSEMBLY (LEFT SIDE) C-00130-026 Steel Pin 3x20 C-00130-045 Aluminum Lever Rear - Red C-00130-059 Spring for Lever Socket Head Screw Button Head Screw Flat Head Screw...
  • Page 9 10 15 REAR SUSPENSION ASSEMBLY (RIGHT SIDE) C-3303-12-16-05 Aluminum Shim Ring ø12x16x0.5 C-00130-020 Wheel Spacer Rear C-00131-080 Main Gear 32DP - 64T...
  • Page 10 10 15 REAR SUSPENSION ASSEMBLY (RIGHT SIDE) C-00130-045 Aluminum Lever Rear - Red C-00130-059 C-00130-026 Steel Pin 3x20 Spring for Lever Socket Head Screw Button Head Screw Flat Head Screw...
  • Page 11 10 15 REAR SUSPENSION ASSEMBLY (LEFT SIDE) C-31025 Aluminum Nylstop Nut M4 C-3201-40 Steel Washer ø4x10x1mm Note the C-370413 orientation Ball Bearing 4x13x4 - Flanged C-30016 Socket Head Screw M4x18...
  • Page 12 10 15 BUMPER ASSEMBLY C-31025 Aluminum Nylstop Nut M4 (3pcs) C-00130-042 Front Bumper C-30062 Flat Head Screws M4x10 (3pcs) Socket Head Screw Button Head Screw Flat Head Screw...
  • Page 13 10 15 BATTERY HOLDER PLATE ASSEMBLY C-13094 Apply CORALLY LOCK-IT 100 SOFT C-30101 Button Head Screw M3x8 (2pcs) C-00130-097 Battery Holder Plate C-00130-018 Aluminum Mount M3x20 (2pcs)
  • Page 14 10 15 RADIO PLATE ASSEMBLY C-13094 Apply CORALLY LOCK-IT 100 SOFT C-00130-096 Carbon Radio Plate C-30050 Flat Head Screws M3x6 (4pcs) Socket Head Screw Button Head Screw Flat Head Screw...
  • Page 15 10 15 RADIO PLATE ASSEMBLY C-31025 Aluminum Nylstop Nut M4 (3pcs) C-00130-040 Silicone Washer C-30066 Flat Head Screws M4x14 (3pcs)
  • Page 16 10 15 RADIO PLATE ASSEMBLY C-31002 Steel Nylstop Nut M3 - Black (4pcs) C-0130-093 Transponder Plate C-0130-092 Chassis Stiffener Plate C-30053 Flat Head Screws M3x12 (4pcs) Socket Head Screw Button Head Screw Flat Head Screw...
  • Page 17 10 15 FRONT SUSPENSION ASSEMBLY NO GLUE Spherical Ball Bushing Bearing 4x12x2.5 Apply CA Glue STICK-IT 100 C-00130-087 Front Lower Suspension Plate...
  • Page 18 10 15 FRONT SUSPENSION ASSEMBLY C-00130-067 Pivot Ball Mounting Block-A C-00130-067 Pivot Ball Mounting Block-A Option Part C-00130-216 C-00130-034 Aluminum Pivot Ball Mounting Ball ø5.8 - M3 - Black Block-A C-30100 Hex Button Head Screw M3x6 C-30030 Socket Head Screw M2.5x6 (8pcs) Socket Head Screw Button Head Screw...
  • Page 19 10 15 SERVO PLATE ASSEMBLY RECOMMANDED C-31002 HIGH SPEED SERVO Steel Nylstop Nut M3 (4pcs) C-52002 - CS-4014 HV - High Speed Low CG Servo C-30101 - High Voltage - Coreless Motor Button Head Screw M3x8 - Titanium Gear (3pcs) C-00130-104 Servo Plate C-00100-083...
  • Page 20 10 15 INSTALLING STEERING SERVO C-30050 Flat Head Screw M3x6 (3pcs) Socket Head Screw Button Head Screw Flat Head Screw...
  • Page 21 10 15 FRONT SUSPENSION ASSEMBLY C-31025 Aluminum Nylstop Nut M4 (2pcs) C-00130-039 Silicon O-Ring 10.5x1.5 (4pcs) C-00130-012 Aluminum Flex Washer (4pcs) C-30064 Flat Head Screws M4x16 (2pcs)
  • Page 22 10 15 FRONT SUSPENSION ASSEMBLY C-13094 Apply CORALLY C-00130-014 LOCK-IT 100 Aluminum 7075 SOFT Front Bulkhead - Right C-00130-013 Aluminum 7075 Front Bulkhead - Left C-30061 Flat Head Screws M4x8 (4pcs) Socket Head Screw Button Head Screw Flat Head Screw...
  • Page 23 10 15 FRONT SUSPENSION ASSEMBLY C-361221 Ball Bearing 12x21x5 (2pcs) C-00130-029 Ball Bearing Inserts (2pcs)
  • Page 24 10 15 CHASSIS STIFFENER ASSEMBLY 28,5 C-16300 Install the pivot ball using the Corally Professional Pliers C-00130-044 Composite Ball Joint ø5.8 - M3 (2pcs) C-00120-044 Turnbuckle 35mm Socket Head Screw Button Head Screw Flat Head Screw...
  • Page 25 10 15 INSTALLING CHASSIS STIFFENER C-00130-034 Ball ø5.8 - M3 C-00100-083 Alu. Shim Ring - 3mm C-30100 Hex Button Head Screw M3x8...
  • Page 26 10 15 FRONT SUSPENSION ASSEMBLY C-31025 Aluminum Nylstop Nut M4 C-370413 Ball Bearing 4x13x4 - Flanged Note the orientation C-00130-054 Aluminum Spacer 4x8x2.8 C-30017 Socket Head Screw M4x22 Socket Head Screw Button Head Screw Flat Head Screw...
  • Page 27 10 15 FRONT DRIVE SHAFT ASSEMBLY C-00130-031 Outdrive Cups C-00130-038 Pulley 28T C-00130-037 Front Drive Axle w/ One-Way Bearings C-00130-031 Outdrive Cups...
  • Page 28 10 15 FRONT SUSPENSION ASSEMBLY C-32100 C-Clips ø12mm C-00130-053 Aluminum Spacer 12x16x2.8 Socket Head Screw Button Head Screw Flat Head Screw...
  • Page 29 10 15 FRONT SUSPENSION ASSEMBLY Option Part C-30030 Socket Head Screw M2.5x6 (8pcs) C-00130-215 Aluminum Pivot Ball Mounting Block-B C-00130-098 Front Upper Suspension Plate C-00130-068 Pivot Ball Mounting Block-B...
  • Page 30 10 15 FRONT SUSPENSION ASSEMBLY C-13094 CASTER C-31205 C-30051 Apply CORALLY Aluminum Flat Head Screw Washer M3 Flat Head Screws M3x8 (4pcs) LOCK-IT 100 (4pcs) SOFT 15° Deg 10° Deg 5° Deg 0° Deg Socket Head Screw Button Head Screw Flat Head Screw...
  • Page 31 10 15 TIMING BELT ASSEMBLY C-00130-032 Timing Belt SSX-8 To adjust the tension of the drive belt • Loosen the socket head screw • Move the belt tensioner Up or Down • Re-tighten the screw...
  • Page 32 10 15 STEERING KNUCKLE ASSEMBLY - L + R L + R C-00130-041 Front Wheel Axle C-361221 Ball Bearing 12x21x5 LEFT RIGHT C-00130-064 Aluminum Adj. Nut M10x1 (2pcs) C-00130-051 Composite Steering Knuckle - Left / Right C-00130-055 Pivot Ball ø8 - M5 (2pcs) C-00130-065 Do not overtighten the Alumini- Composite Washer for Pivot Ball (2pcs)
  • Page 33 10 15 STEERING KNUCKLE ASSEMBLY - L + R L + R C-00130-034 Ball ø5.8 - M3 - Black C-00130-026 Steel Pin 3x20 C-31500 Shim Rings 12x18x1.0 (2pcs) C-30100 C-00130-059 Button Head Screw M3x6 Spring for Lever C-00130-046 Aluminum Lever Front - Red...
  • Page 34 10 15 STEERING KNUCKLE ASSEMBLY L + R 0° Deg Camber 25 mm 25 mm C-30195 Low Profile Nut M5 (2pcs) C-00130-043 Drive Shaft Front L + R Socket Head Screw Button Head Screw Flat Head Screw...
  • Page 35 10 15 FRONT BODY MOUNT ASSEMBLY C-13094 Apply CORALLY C-00130-010 LOCK-IT 100 Body Mount Post - Red (2pcs) SOFT C-00130-007 Front body mount plate C-30101 Button Head Screw M3x6 (2pcs)
  • Page 36 10 15 STEERING KNUCKLE ASSEMBLY L + R C-13094 C-30052 Apply CORALLY Flat Head Screws M3x10 (2pcs) LOCK-IT 100 SOFT C-31205 Aluminum Flat Head Screw Washer M3 (2pcs) Socket Head Screw Button Head Screw Flat Head Screw...
  • Page 37 10 15 STEERING LINKAGE ASSEMBLY C-00130-017 C-00130-044 Turnbuckle 62mm Composite Ball Joint ø5.8 - M3 (2pcs) C-16300 Install the pivot ball using the Corally Professional Pliers...
  • Page 38 10 15 REAR BODY MOUNT ASSEMBLY C-13094 Apply CORALLY C-00130-019 LOCK-IT 100 Body Mount Spacer (2pcs) SOFT C-30052 Flat Head Screws M3x10 (4pcs) C-31205 Aluminum Flat Head Screw Washer M3 (4pcs) C-00130-005 Bulkhead Stiffener Plate C-30062 Flat Head Screws M4x10 Socket Head Screw Button Head Screw Flat Head Screw...
  • Page 39 10 15 REAR BODY MOUNT ASSEMBLY C-13094 Apply CORALLY LOCK-IT 100 SOFT C-30062 Flat Head Screws M4x10 (2pcs) C-00130-010 Body Mount Post - Red (2pcs) C-31215 Aluminum Flat Head Screw Washer M4 (2pcs) C-3034-60-30 Nylon Screw M6x30 (2pcs) C-30051 Flat Head Screws M3x8 (2pcs) C-00130-099 Body Mount Plate Rear...
  • Page 40 10 15 MOTOR ASSEMBLY RECOMMANDED BRUSHLESS MOTOR C-61302 Brushless Motor Dynospeed VELOX 805 (Not Included) 1/8 Sensored 4-Pole Competition Brushless Motor - 1950 KV Please select the appropriate screws for your motor C-72514 32 DP Pinion - Short - Hardened Steel - 14 Teeth - Shaft Dia.
  • Page 41 10 15 REAR BODY MOUNT ASSEMBLY Receiver (Not Included) C-00100-015 Antenna Mount C-31015 Double-Side Tape Aluminum Nylstop Nut M3 (Not included) (2pcs) Transponder holder (Not Included) RECOMMANDED SPEEDCONTROLLER Speedcontroller C-53004-1 (Not Included) REVOC PRO 160 2-6S Esc For Sensored And Sensorless Motors - 160A C-30050 C-30050...
  • Page 42 10 15 COOLING FAN ASSEMBLY C-00130-081 Fan Mounting Plate C-53103 Ultra High Speed Cooling C-30101 option) Fan 40mm ( Button Head Screws M3x8 (2pcs) C-30054 Flat Head Screws M3x16 (4pcs) C-31015 Alu. Nylstop Nut M3 (4pcs) C-31015 Aluminum Nylstop Nut M3 Socket Head Screw Button Head Screw Flat Head Screw...
  • Page 43 10 15 BASIC CAR SET-UP 0° Deg 25 mm Camber Block B Block A 25 mm Block A Block B + 2.4mm Ground Clearance Ground Clearance CASTER 15° Deg 10° Deg 5° Deg 0° Deg...
  • Page 44 10 15 BATTERY CABLE SUPPORT PLATE ASSEMBLY C-30101 Button Head Screw M3x8 (2pcs) C-00130-100 Battery Cable Support Plate Carbon C-00130-018 Aluminum Mount M3x20 (2pcs) C-30101 Button Head Screw M3x8 (2pcs) Socket Head Screw Button Head Screw Flat Head Screw...
  • Page 45 10 15 WHEEL INSTALLATION SSX-8 FOAM TIRES C-14713-30 Front Foam Tyres - 30 Shore C-14713-32 Front Foam Tyres - 32 Shore C-14713-35 Front Foam Tyres - 35 Shore are not included Rims and Tyres C-14718-32 Rear Foam Tyres - 32 Shore C-14718-35 Front Foam Tyres - 35 Shore...
  • Page 46 10 15 BATTERY CONFIGURATION SHORTY FRONT SHORTY REAR LATERAL SHORTY REAR REAR REAR REAR FRONT FRONT FRONT For this config, use (2x) For this config, use (2x) For this config, use (2x) C-49505 C-49505 C-49505 Voltax 120C LiPo Battery Voltax 120C LiPo Battery Voltax 120C LiPo Battery 5000mAh - 7.4V - Shorty 2S 5000mAh - 7.4V - Shorty 2S...
  • Page 47 10 15 BATTERY CONFIGURATION 1x 4S LEFT 2x 2S REAR REAR FRONT FRONT For this config, use (2x) For this config, use C-49523 C-49530 Voltax 120C LiPo Battery Voltax 120C LiPo Battery 8000mAh - 7.4V - Stick 2S 8000mAh - 14.8V - Stick 4S...
  • Page 48 SPARE PARTS Body Mount Post C-00100-015 Antenna Mount C-00130-010 4 Pcs Alum. Shim Ring - ID 3mm - OD C-00100-083 C-00130-012 Aluminum Flex Washer 4 Pcs 5mm - 3mm - 5 pcs Aluminum 7075 C-00120-044 Turnbuckle 35mm C-00130-013 Front Bulkhead - Left 1 Pc Rear Bulkhead Stiffener Plate Aluminum 7075...
  • Page 49 SPARE PARTS Composite Ball Aluminum Body C-00130-029 Bearing Inserts C-00130-019 Mount Spacer 4 Pcs 2 Pcs One-Way Outdrive Cups Aluminum Rear C-00130-031 Steel C-00130-020 Shaft Spacer 2 Pcs Timing Belt SSX-8 Aluminum 7075 C-00130-032 C-00130-023 1 Pc Rear Bulkhead - Left Ball Aluminum 7075 ø5.8mm - M3...
  • Page 50 SPARE PARTS Silicone O-Ring 10.5x1.5 Aluminum Lever - Rear C-00130-039 C-00130-045 8 Pcs 2 Pcs Aluminum Lever - Front Silicone Washer C-00130-040 C-00130-046 2 Pcs 2 Pcs Front Wheel Axle Chrome Steel C-00130-050 Composite Pulley - 32T C-00130-041 2 Pcs Composite Pivot Ball Steering Knuckle C-00130-042 Front Bumper...
  • Page 51 SPARE PARTS Composite Pivot Ball Mounting Pivot Ball - M5 C-00130-055 C-00130-068 Block - B-Block 4 Pcs 2 Pcs Shim Ring - Aluminum Fan Mounting Plate SSX-8 3K Carbon C-00130-056 ø12x16x1mm C-00130-081 4 Pcs 1 Pc Front Lower Suspension Plate Spring for Lever C-00130-087 3K Carbon + Spherical Balls (2)
  • Page 52 SPARE PARTS Chassis Stiffener Plate Battery Cable Support Plate C-00130-092 C-00130-100 3K Carbon 3K Carbon Transponder Plate Servo Plate SSX-8 C-00130-093 C-00130-104 3K Carbon 3K Carbon Radio Plate SSX-8 Composite Main Gear C-00130-096 C-00131-080 3K Carbon 32DP - 64T Battery Plate SSX-8 C-00130-097 3K Carbon C-10124...

  • Page 53: Socket Head Screw Din 912

    SPARE PARTS Aluminum Flat Head Screw Ball Bearing - Abec 3 Washer C-361221 12x21x5 C-31205 M3 - Red 4 Pcs 10 Pcs Ball Bearing - Abec 3 Aluminum Flat Head Screw 4x13x4 Washer C-370413 C-31215 Flanged M4 - Red 4 Pcs 10 Pcs Steel Nylstop Nut M3 - Black Nylon Nut - M6...

  • Page 54: Table Of Contents

    SPARE PARTS Flat Head Screw Socket Head Screw DIN 912 DIN 7991 M4 x 22 C-30017 C-30062 M4 x 10 10 Pcs 10 Pcs Flat Head Screw Flat Head Screw DIN 7991 DIN 7991 C-30050 C-30066 M3 x 6 M4 x 14 10 Pcs 10 Pcs Flat Head Screw...

  • Page 55: Pcs

    SPARE PARTS Steel Washer ø4x10x1mm C-3201-40 10 Pcs Shim Ring - Aluminum C-3303-12- ø12x16x0.5mm 16-05 4 Pcs...
  • Page 56 SPARE PARTS OPTIONAL PARTS Pinion 32 DP - 5mm Shaft 12 C-72512 Teeth Aluminum Pivot Ball Mounting Pinion 32 DP - 5mm Shaft 13 Block - B C-00130-215 C-72513 Teeth 2 Pcs Aluminum Pivot Ball Mounting Pinion 32 DP - 5mm Shaft 15 C-00130-216 Block - A C-72515...
  • Page 57 TIRE TRACTION COMPOUNDS Tire Juice 22 Tire Juice 33 Tire Juice 44 Tire Juice 55 GREEN 100ml RED 100ml YELLOW 100ml BLUE 100ml C-13760 Tire Juice 22 C-13761 Tire Juice 33 C-13762 Tire Juice 44 C-13763 Tire Juice 55 RUBBER - ASPHALT FOAM - ASPHALT RUBBER - CARPET FOAM - CARPET...
  • Page 59 This manual is an edition of Team Corally, Geelseweg 80, B-2250 OLEN (Belgium). This manual is protected by a copyright and nothing from this edition may be reproduced or used without any prior written authorisation. Whilst every effort has been made to ensure the accuracy of the information in this catalogue, errors do creep in and Team Corally can accept no responsibility for failures, wrong specifications, accuracy of colours, losses or damages caused.
  • Page 60 Team Corally • Geelseweg 80 • 2250 Olen • Belgium Tel: +32 14 25 92 94 • info@corally.com • www.corally.com...
