  • Page 1 www.corally.com C-00165_manual-V1...

  • Page 2: Read First

    INTRODUCTION Thank you for purchasing a Team Corally car. This manual describes the instructions for using the model and the elec- tronic components. You will also find some tips on how to maintain your RC model so that you can enjoy it for years to come.

  • Page 3: Use Precautions

    Take all necessary precautions before, during and after using your model. You are responsible for the safe as- sembly, maintenance and use of your model. In case of any questions, contact your local reseller or contact Team Corally support for assistance. SAFETY PRECAUTIONS For your safety, always use wear gloves and goggles when assembling and maintaining your model.

  • Page 4: Warranty

    If material defects or manufacturing faults should arise in a product distributed or manufactured by Team Corally / JSP Group Intl bvba, and purchased by a consumer, we Team Corally / JSP Group Intl bvba acknowl- edge the obligation to correct those faults or defects within the limitations described below. This manufacturers warranty is in addition to, and does not affect, the legal or contractual rights of the consumer which arise from the purchase of such products.
  • Page 5 LIPO BATTERY SAFETY PRECAUTIONS • Follow and respect the manufacturer’s instructions for use • It is important to check that your ESC is set to LIPO if you are using a LIPO battery. Failure to comply with this instruc- tion will result in increased battery discharge and may cause fire and damage to persons and property. •...

  • Page 6: Car Components

    CAR COMPONENTS Front Differential Suspension Arm Front Shock Absorber Anti-Roll Bar Steering Block Steering Link Steering Servo Speed Controller (ESC) Power Switch Receiver Box Centre Differential Brushless Motor Battery compartment Rear Shock Absorber Rear Suspension Arm Wheel Axle Anti-Roll Bar Rear Upright Turnbuckle Rear Differential...
  • Page 7 QUICK START GUIDE READ THE INSTRUCTIONS CHARGE THE BATTERY INSTALL 4x AA BATTERY CHARGER BATTERY MAKE SURE THAT ALL SCREWS AND NUTS ARE INSTALL THE BATTERY TURN ON THE TRANSMITTER (Always First) TIGHTENED PROPERLY. 1. CONNECT THE BATTERY TO THE ESC CHECK THE FUNCTIONS CHECK THE RADIO SYSTEM RANGE 2.

  • Page 8: Maintenance

    MAINTENANCE DIFFERENTIAL MAINTENANCE It may be necessary to replace the silicone oil every 50 runs. It depends on how you drive and the type of terrain you drive on. • 1. Remove 2 screws under the chassis. • 2. Remove the 2 shock absorber fixing screws. Rotate the shock absorbers upwards •...
  • Page 9 MAINTENANCE SHOCK ABSORBER MAINTENANCE It may be necessary to replace the silicone oil in the shock absorbers every 40 runs. It depends on how you drive and the type of terrain you drive on. Remove the shock absorbers from the vehicle. (4x) Remove the shock cap.
  • Page 10 FRONT DRIVE TRAIN - EXPLODED VIEW...
  • Page 11 REAR DRIVE TRAIN - EXPLODED VIEW...

  • Page 12: Chassis - Exploded View

    CHASSIS - EXPLODED VIEW...

  • Page 13: Spare Parts

    SPARE PARTS SEE SPARE PARTS AT www.corally.com C-00180-004 C-00180-004-1 C-00180-005 C-00180-013 Battery - ESC Tray - Composite Battery Strap - Hook & Loop Wing Mount - Adjustable - Servo Mount - Receiver Box - - 1 pc - 2 pcs Composite - 1 Set Composite - 1 Set C-00180-015...
  • Page 14 SPARE PARTS C-00180-102 C-00180-104 C-00180-109 C-00180-106 C-00180-107 Chassis Brace - Front - Com- Shock Tower Brace - Front - Caster Clips Set - 1 to 4.5mm Body Post - Front - Composite Body Post - Rear - Composite posite - 1 pc Composite - 1 pc - 1 Set - 2 pcs...
  • Page 15 SPARE PARTS C-00180-177 C-00180-178 C-00180-179 C-00180-182 C-00180-183 Motor Mount - Aluminium - 1 pc Diff. Bevel Gear 43T - Steel - Planetary Diff. Gears - Steel - O-Ring - Silicone - 5x8mm - Diff. Gasket - 4 pcs 1 pc 1 Set 5 pcs C-00180-184...
  • Page 16 SPARE PARTS C-00180-300 C-00180-301 C-00180-305 C-00180-307 C-00180-316 Wheelie Bar Spacer - Aluminium Centre Roll Cage Mount - Com- Centre Roll Cage Pin - Steel - Wheelie Bar Plate - Aluminium Shock Cap - Lower - Aluminium - 1 pc posite - 1 Set 2 pcs - 1 pc - 2 pcs...

  • Page 17: Option Parts

    OPTION PARTS C-00180-139 C-00180-140 C-00180-141 C-00180-003 C-00180-046 Suspension Arm Mount PRO - Suspension Arm Mount PRO - Suspension Arm Mount PRO - Steering Top Plate - Graphite Eccentric Bushings Set - 2mm - 1 pc Composite - 1 Set FR-FR - Aluminum 7075 - 1 pc FR-RE - Aluminum 7075 - 1 pc RE-FR - Aluminum 7075 - 1 pc C-00180-142...
  • Page 18 OPTION PARTS C-00180-275 C-00180-278 C-00180-279 C-00180-280 C-00180-282 Susp. arm stiffener - B - Lower Front Suspension Arm Pivot Pin - Suspension Arm Pivot Pin - Shock Shaft - 66mm - Rear - Shock Shaft - 61mm - Front - - Left - Graphite 1.5mm - 1 pc Lower Inner - FR/RE - TiNi - 2 pcs Upper - Front - TiNi - 2 pcs TiNi - 2 pcs...

  • Page 19: Declaration Of Conformity

    NOTE DECLARATION OF CONFORMITY EU-Konformitätserklärung/ Déclaration de Conformité UE (in accordance with ISO/IEC 17050-1) / (in Übereinstimmung mit ISO/IEC 17050-1) / (Conformément à la norme ISO/IEC 17050-1) Description : 1/8 DEMENTOR MONSTER TRUCK 4WD - RTR Item Number: C-00165 This declaration is issued under the sole responsibility of the manufacturer. Die alleinige Verantwortung für die Ausstellung dieser Erklärung trägt der Hersteller.
