SHOCK ABSORBER MAINTENANCE
It may be necessary to replace the silicone oil in the shock absorbers every 40 runs.
It depends on how you drive and the type of terrain you drive on.
Remove the shock absorbers from the car. (4x)
FILL THE SHOCK ABSORBERS WITH NEW SILICONE OIL
FILL
• Pull the Shock shaft
• Move the piston up&down
down.
• Fill the shock body with
silicone oil.
• Front : 450cps
Rear : 400cps
TRACK USE
OFF-ROAD
BASHING
.www. corally.com/Chemicals/Silicone-Oils/
10
MOVE
WAIT
UP
5min
• Pull the Shock shaft
(3-4x) to release the air
down.
bubbles in the silicone
• Install the shock absorb-
oil.
er vertically and let it sit
for a few minutes until
the bubbles rise to the
surface.
FRONT
SILICONE OIL
SPRING TENSION
450CPS
4mm
600CPS
4mm
650CPS
4mm
SPRING TENSION
Remove the shock cap.
ALWAYS USE SILICONE OIL, NEVER USE ANY OTHER TYPES OF OIL.
TIGHTEN
50%
• Install the silicone mem-
brane in the shock cap.
• Tighten slightly the
shock cap on the shock
body.
• A little oil will flow out of
the shock absorber.
SILICONE OIL
400CPS
500CPS
550CPS
Drain the oil from the shock absorber.
MOVE
UP
• Gently move the piston
• Allow the piston in the
in upper position.
upper position.
• The excess will flow out
• Tighten the cap fully but
of the shock absorber.
not too much otherwise
the membrane will be
deformed.
REAR
SPRING TENSION
0mm
6 Holes Ø1.3mm
0mm
6 Holes Ø1.3mm
0mm
6 Holes Ø1.3mm
TIGHTEN
FULLY
SHOCK PISTON
