Taking a Closer Look

Front/Open View

No. Names of Parts
1 Locking/Unlocking screw
2 TMA
3 Glass Surface
4 Vertical Ruler
5 Smart-Touch button (Scan)
6 POWER Indicator (Amber)
7 READY Indicator (Green)
8 U-shaped (Horizontal) Ruler
Functions of Parts
Used to lock and unlock the TMA.
Transparent Media Adapter is used to scan X-ray films.
Scan bed for scanning X-ray films.
Used to measure the length of the images.
Press to execute the scan function fast.
Indicates the digitizer is on or off.
Indicates the status of the digitizer. For more details, refer
to the "Troubleshooting" section of this manual.
Used to measure the width of the images.
MII-800XL Plus User's Manual 11
