NOTE:
elctrostatic discharge!
Observe the necessary safety
precautions when handling compo-
nents that are vulnerable to
electrostatic discharge (EN 61340-5-1 and IEC
61340-5-1)!
The models MDH830, MDH810 and MDH815 may only be operated and connected on a tele-
phone switchboard but not directly operated on the public telephone network.
6

Router installation

6.1 Installation position / minimum
distances
The mbNET router is for mounting on DIN rails (according
to DIN EN 50 022) designed and intended for the control
cabinet installation.
Installation and mounting must be in accordance with
VDE 0100 / IEC 364. The router may only be mounted in
a vertical position as described.
Non-compliance with the minimum distances can
destroy the device at high ambient temperatures!
NOTICE
- 8 -
The mbNET routers are maintenance-free
units.
If an mbNET router have damage or malfun-
ction, the device must be immediately taken
out of service and secured against inadvertent
operation.
NOTICE
20
mm
20
mm
