PHYWE Cobra4 Operating Instructions

PHYWE Systeme GmbH & Co. KG
Robert-Bosch-Breite 10
D-37079 Göttingen
Phone +49 (0) 551 604-0
Fax +49 (0) 551 604-107
E-mail info@phywe.de
Operating instructions
The unit complies with
the corresponding EC
guidelines.
CONTENTS
1

SAFETY PRECAUTIONS

2 Purpose And Characteristics
3 Functional And Operating Elements
3.1 Operating elements
3.2 Sensor interface
4 Notes On Operation
5 Handling
5.1 Putting Into Operating
5.2 Recording Of Temperatures
6 Technical Specifications
7 Parts Supplied
8 Accessories
9 Notes On The Guarantee
10 WASTE DISPOSAL
www.phywe.com, © All rights reserved
2 x Temperature, NiCr-Ni
Fig. 1: 12630.00 Cobra4 Sensor-Unit 2 x Temperature, NiCr-Ni
Cobra4 Sensor-Unit
1 SAFETY PRECAUTIONS
Carefully read these operating instructions completely
•
before operating this instrument. This is necessary to
avoid damage to it, as well as for user-safety.
Only use the Cobra4 Sensor-Unit 2 x Temperature,
•
NiCr-Ni for the purpose for which it is intended.
Only use the instrument in dry rooms in which there is no
•
risk of explosion.
Protect Cobra4 Sensor-Unit 2 x Temperature, NiCr-Ni
•
from dust, moisture and vapours. Use a slightly moist lint-
free cloth to clean the instrument. Do not use aggressive
cleaning agents or solvents.
Do not open the housing of the Cobra4 Sensor-Unit.
•
Only connect the data output of Cobra4 Sensor-Unit to
•
the measured value recording instruments intended for it.
The present-day state of software development makes it
•
impossible to guarantee that a product is free of faults.
PHYWE Systeme GmbH & Co. KG therefore does not
take on any liability for damages that occur during the in-
stallation or the use of the instrument.
2 PURPOSE AND CHARACTERISTICS
Cobra4 Sensor-Unit 2 x Temperature NiCr-Ni serves for the
measurement of a maximum of two temperatures simultane-
ously. According to the type of application, this Cobra4 Sen-
sor-Unit can be connected to the following measured value
recording instruments for transmittance of measured values
to them;
12641.00
1
12641.00 / 4808
