PHYWE Cobra4 Sensor-Unit Tesla Operating Instructions

PHYWE Systeme GmbH & Co. KG
Robert-Bosch-Breite 10
D-37079 Göttingen
Phone +49 (0) 551 604-0
Fax +49 (0) 551 604-107
E-mail info@phywe.de
Operating instructions
The unit complies with
the corresponding EC
guidelines.
CONTENTS
2 PURPOSE AND CHARACTERISTICS
3 FUNCTIONAL AND OPERATING ELEMENTS
4 NOTES ON OPERATION
5 HANDLING
6 TECHNICAL SPECIFICATIONS
7 PARTS SUPPLIED
8 ACCESSORIES
9 NOTES ON THE GUARANTEE
10 WASTE DISPOSAL
www.phywe.com, © All rights reserved
Cobra4 Sensor-Unit Tesla, ± 1 Tesla
Fig. 1: 12652-00 Cobra4 Sensor-Unit Tesla.
1 SAFETY PRECAUTIONS
Read these operating instructions carefully and com-
•
pletely before putting your Cobra4 Sensor-Unit Tesla into
operation. In addition, also similarly read the operating
instructions for the transmission device (Cobra4 Wire-
less-Link, Cobra4 USB-Link or Cobra4 Mobile-Link) that
is to be used for the acquisition of measured values be-
fore operating the Sensor-Unit. With these measures you
protect yourself and your equipment.
Only use the instrument for the purpose for which it was
•
designed.
Only use the instrument in dry rooms in which there is no
•
risk of explosion.
Protect your Cobra4 Sensor-Unit Tesla from dust, mois-
•
ture and vapours. Clean it with a slightly moist, lint-free
cloth. Aggressive cleaning agents and solvents are un-
suitable.
Take care that no liquid penetrates in through the open-
•
ings in the housing, as the Cobra4 Sensor-Unit Tesla
would then suffer damage.
When using the Sensor-Unit outdoors, ensure that nei-
•
ther rainwater nor spray penetrate into the housing.
Only use the experimental set-up for the use for which it
•
is intended.
Do not open the Sensor-Unit..
•
Only connect the data output of the Cobra4 Sensor-Unit
•
Tesla to one of the three measured data recording in-
struments that are intended for it.
The present-day state of software development makes it
•
