PHYWE Cobra4 Sensor-Unit Energy Operating Instructions

PHYWE Systeme GmbH & Co. KG
Robert-Bosch-Breite 10
D-37079 Göttingen
Phone +49 (0) 551 604-0
Fax +49 (0) 551 604-107
E-mail info@phywe.com
Operating instructions
The unit complies with
the corresponding EC
guidelines.
CONTENTS
1 SAFETY PRECAUTIONS
2 PURPOSE AND CHARACTERISTICS
3 FUNCTIONAL AND OPERATING ELEMENTS
3.1 Operating elements
3.2 Functional elements
4 NOTES ON OPERATION
5 HANDLING
5.1 Putting Cobra4 Sensor-Unit Energy into operation
6 TECHNICAL SPECIFICATIONS
7 PARTS SUPPLIED
8 NOTES ON THE GUARANTEE
9 WASTE DISPOSAL
www.phywe.com, © All rights reserved
Cobra4 Sensor-Unit Energy
Fig. 1: 12656-00 Cobra4 Sensor-Unit Energy
1 SAFETY PRECAUTIONS
Carefully read these operating instructions completely
•
before operating this instrument. In addition, please simi-
larly read the operating instructions for the measured
data recording instrument (Cobra4 Wireless-Link, Cobra4
USB-Link, Cobra4 Junior-Link or Cobra4 Mobile-Link)
that is to be used. This is necessary to avoid damage to
it, as well as for user-safety.
Only use the instrument for the purpose for which it was
•
designed.
Only use the instrument in dry rooms in which there is no
•
risk of explosion.
Protect Cobra4 Sensor-Unit Energy from dust, moisture
•
and vapours. Use a slightly moist lint-free cloth to clean
the instrument. Do not use aggressive cleaning agents or
solvents.
Take care that no liquid penetrates in through the hous-
•
ing openings, as such penetration would result in dam-
age to Cobra4 Sensor-Unit Energy.
When using the instrument in the open air, do not allow
•
rainwater or splash water to enter into the housing.
Do not open up the instrument.
•
Only connect the data output of Cobra4 Sensor-Unit En-
•
ergy to the measured data recording instruments specifi-
cally intended for it.
• The present-day state of software development makes it
impossible to guarantee that a product is free of faults.
PHYWE Systeme GmbH & Co. KG therefore does not
take on any liability for damages that occur during the in-
stallation or the use of the instrument.
12656-00
1
12656-00 / 2311
