Cobra4 Sensor-Unit Pressure, 7 bar absolute
Fig. 1: 12647-00 Cobra4 Sensor-Unit Pressure, 7 bar absolute
1

SAFETY INSTRUCTIONS

Read the operating instructions thoroughly and complete-
•
ly prior to starting the Cobra4 Sensor-Unit "Pressure,
7 bar absolute". The operating instructions of the data
transfer device that is used in combination with the Sen-
sor-Unit for recording the measurement values (Cobra4
Wireless-Link, Cobra4 USB-Link, Cobra4 Junior-Link, or
Cobra4 Mobile-Link) must also be read. This is important
for your own protection and for avoiding damage to the
units.
Use the Cobra4 Sensor-Unit "Pressure, 7 bar absolute"
•
solely for its intended purpose.
The unit is intended for use in dry rooms where there is
•
no risk of explosion.
Protect the Cobra4 Sensor-Unit "Pressure, 7 bar abso-
•
lute" against dust, humidity, and vapours. Clean the unit
with a slightly moist, lint-free cloth. Do not use any ag-
gressive cleaning agents or solvents.
Do not open the housing of the Cobra4 Sensor-Unit
•
"Pressure, 7 bar absolute".
Ensure that no liquids penetrate the housing of the Sen-
•
sor-Unit, since otherwise the Sensor-Unit would be dam-
aged.
Connect the data output of the Cobra4 Sensor-Unit
•
"Pressure, 7 bar absolute" solely to the intended mea-
surement data recording devices and sensors.
12647-00
