Cobra4 Junior-Link
Fig. 1: 12615-00 Cobra4 Junior Link
1
SAFETY PRECAUTIONS
Carefully read these operating instructions completely
•
before operating this instrument. This is necessary to
avoid damage to it, as well as for user-safety.
Only use the instrument for the purpose for which it was
•
designed.
Only use the instrument in dry rooms in which there is no
•
risk of explosion.
Protect Cobra4 Junior-Link from dust, moisture and va-
•
pours. Use a slightly moist lint-free cloth to clean the in-
strument. Do not use aggressive cleaning agents or sol-
vents.
Only use the experimental set-up for the purpose for
•
which it is intended.
Do not open the instrument.
•
Supply Cobra4 Junior-Link exclusively via a USB con-
•
nection (PC or USB hub).
The present-day state of software development makes it
•
impossible to guarantee that a product is free of faults.
PHYWE Systeme GmbH & Co. KG therefore does not
take on any liability for damages that occur during the in-
stallation or the use of the instrument.
2
PURPOSE AND CHARACTERISTICS
Cobra4 USB-Link enables communication to be made be-
tween a PC with a USB interface and a Cobra4 Sensor-Unit
(Fig. 2). It is equipped with a D-Sub 15 socket for linkage to
12615-00
1
12615.00 / 2111
