STEP 3
- Removing Dogging
A. Remove Cylinder by pulling up.
C. Using Hammer & Pin Punch knock rivets
out.
E.
Using Pliers or Vise grips to attach onto flat
part of dogging tail piece closest to where
it connects to metal rod.
Cylinder
Rivets
Dogging tail
If using a hacksaw cut here
*If you have a fire-rated
device skip to step 4
B. Push tabs in & pull up on locking
piece.
Tabs
D. Or drill rivets out using 3/16 drill
bit.
F.
Rotate towards than away from you
until you hear the part snap than
remove.
Page 4
Locking piece
