I N S T A L L A T I O N I N S T R U C T I O N S
The Command Access VLP-M-KIT is a field-installable motorized latch-pullback baserail kit for the Von
K i t I n c lude s
A.
1 - VLP-M-KIT Baserail Kit
B.
1 - 6' Lead
C.
1 - Dogging Hole Cap
U.S. Customer Support
1-888-622-2377
VLP-M-KIT
Duprin 33/35 & 98/99 series devices.
A.
B.
Visit our website for more details
www.CommandAccess.com
C.
To o l s R eq ui red
•
Cordless Drill
•
5/16 Nut driver (recommended) or Flat head
screwdriver
•
#2 Phillips head screwdriver
Additional
Information
1
Canada Customer Support
1-855-823-3002
02/16 Doc # 20272_E

Advertisement

loading
Need help?

Need help?

Do you have a question about the VLP-M-KIT and is the answer not in the manual?

Questions and answers

Related Manuals for Command access VLP-M-KIT

Summary of Contents for Command access VLP-M-KIT

  • Page 1 I N S T A L L A T I O N I N S T R U C T I O N S The Command Access VLP-M-KIT is a field-installable motorized latch-pullback baserail kit for the Von Duprin 33/35 & 98/99 series devices.

  • Page 2: Technical Information

    Technical Information Specifications MM4 Switches • Input Voltage: 24VDC +/- 10% • Average Latch Retraction Current: 1 Amp • Average Holding Current: 170 mA • Wire gauge: Minimum 20 gauge PTS Video Click or Scan etting **Important Info** Make sure to set PTS before finishing installation! Step 1 Press the device push pad to the desired setting.
  • Page 3 • Remove head cover. • Remove mounting bracket. Bracket Head cover • Remove (2) screws attaching bracket • Remove case for device. to baserail with 5/16 nut driver or flat head screw driver. Case Screws • Remove push pad by pulling pad •...
  • Page 4 • Remove the “C” clip and pin attaching • Swap your mechanical baserail for the the latch to the baserail. electrified baserail. • Re-install “C” clip attaching the latch • Re-install the pin into the first hole to the new baserail. •...
  • Page 5 • Replace push pad by placing over • Slide baseplate back into case being activating arms & pushing down then careful of motor wires. back towards end of device. Case Push pad • Replace bracket & attach (2) screws with 5/16 •...
