RGBlink VENUS X1PRO-E Quick Start Manual page 10

6. After the digital, push the knob will add *, means before the * is the horizontal size. Same operation for
vertical size, for example input1536 as following:
7. After the digital, push the knob will add @, means before the @ is the vertical size, and after the @ is the
refresh rate. Only digital 50 or digital 60 supports for the refresh rate. Use the digital buttons to finish the
settings. For example, input refresh rate 60:
8. After input all the values, push the knob to enable VENUS X1PRO -E to output this resolution. VENUS
X1PRO-E will take 1~2 seconds to enable this output resolution.
Image Select
1. Push the [MENU] button, default to <Standard> menu,
2. Push the knob to confirm, turn the rotary knob and select the <Image Select>, push the knob to confirm.
3. Turn the rotary knob to set the follows parameters as needed.
9
Address：S601-607, S504 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
Customs:
*1536×
Customs:
*1536×1536@
Customs:
->1536×1536@60
->Standard
Customs
Output Resolution
->Image Select
->Image Select
Image 1 Source
Width
Height
>>
>>
>>
>>
Mode 1
DVI1
1300
1080
