- Page 1 USER MANUAL OAKWORKS ® Treatment Tables Powerline Series Seychelle Series ™ www.oakworks.com · 717.235.6807...
- Page 2 OAKWORKS , Inc. tial damages in connection with or ® arising out of the furnishing, per- formance, or use of this document OAKWORKS is a registered and the program material which it ® trademark of OAKWORKS , Inc. describes. ®...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Product Use Description ..................... 1 Important Safety Instructions ..................... 1 Product Description & Photo Powerline Series ......................2-3 Seychelle Series ......................4-5 Installation Table Assembly......................6 Inset Shelf ........................6 Directions for Use Paper Roll Holder Use ....................7 Wave Backrest Use ....................... -
Page 4: Product Use Description
PRODUCT USE DESCRIPTION / IMPORTANT SAFETY INSTRUCTIONS PRODUCT USE DESCRIPTION The Oakworks Powerline & Seychelle Tables are used to support the patient during exam- inations and procedures. They are intended to be operated by a professional in a exam/ treatment environment. No special training is required but a review of the following manual is important for the safety of the operator and patient. -
Page 5: Product Description & Photo
PRODUCT DESCRIPTION Powerline Flat Top Accessory outlets Upholstered Top Accessory outlets QuickLock Face Rest (accessory) Paper Roll Holder Table Extender (accessory) STANDARD SPECIFICATIONS Height Range Fixed 30” (76 cm.) Table Capacity 500 lbs. (226 kg.) (patient and accessories) Widths 27” (69 cm.) or 30” (76 cm.) Length 72”... - Page 6 PRODUCT DESCRIPTION Powerline Wave Backrest Wave Backrest QuickLock Face Rest (accessory) Upholstered Top Accessory outlets Table Extender (accessory) Paper Roll Holder Accessory outlets Inset Shelf (option) STANDARD SPECIFICATIONS Table Height Fixed 30” (76 cm.) Wave Backrest Manual 0-60º, 6 set positions Table Capacity 500 lbs.
-
Page 7: Seychelle Series
PRODUCT DESCRIPTION Seychelle Flat Top Accessory outlets Upholstered Top Accessory outlets QuickLock Face Rest (accessory) Inset Shelf (option) Table Extender (accessory) STANDARD SPECIFICATIONS Height Range Fixed 30” (76 cm.) Table Capacity 500 lbs. (226 kg.) (patient and accessories) Widths 27” (69 cm.) or 30” (76 cm.) Length 72”... - Page 8 PRODUCT DESCRIPTION Seychelle Wave Backrest Wave Backrest QuickLock Face Upholstered Top Rest (accessory) Accessory outlets Table Extender (accessory) Accessory outlets Inset Shelf (option) STANDARD SPECIFICATIONS Table Height Fixed 30” (76 cm.) Wave Backrest Manual 0-60º, 6 set positions Table Capacity 500 lbs.
-
Page 9: Installation
INSTALLATION TABLE ASSEMBLY NOTE: Retighten all bolts after 4 weeks; the wood will naturally experience slight shrinkage, which can cause the bolts to loosen. SUPPLIED PARTS: LEG HARDWARE LEG BRACE TOOLS 8 -Reinforcement Plates 1 - Wood Leg Brace 1 - Large Allen Wrench 8 - Belleville Washers 2 - Short Bolts 1 - Small Allen Wrench... -
Page 10: Directions For Use
DIRECTIONS FOR USE PAPER ROLL HOLDER USE After the table is set-up, Using the supplied Locate the wooden To secure the wooden locate the hole in the leg. screw & allen wrench, dowel & feed it thru dowel on the other secure the paper roll your paper roll. -
Page 11: Quicklock Face Rest
DIRECTIONS FOR USE QUICKLOCK FACE REST * U.S. Patent #5,177,823 CAUTION Do not put excessive weight or pressure on the Quicklock Face Rest. Do not extend the dowels of the Quicklock Face Rest 3” (7.6 cm.) from the table top. The Maximum Weight Capacity for the QuickLock Face Rest is 25 lbs. -
Page 12: Cleaning & Disinfection
• Retighten all bolts after 4 weeks; the wood will naturally experience slight shrinkage, which can cause the bolts to loosen. • Oakworks tables/chairs are designed and built to provide many years of dependable service. Please fol- low local regulations and laws when disposing of the components used in this table. -
Page 13: Model Number & Serial Number
Not Used Fabric: TerraTouch Padding FR=1.75” (4 cm.) Firm Response SF=2.5” (6 cm.) Semi-Firm PL=3” (8 cm.) Comfort AC=4” (10 cm.) Comfort Table Top Length Minimum Table Height Table Width FT=Flat Top BR=Wave Backrest Base Table PW=Powerline Series SE=Seychelle Series... -
Page 14: Specifications
SPECIFICATIONS PRODUCT SPECIFICATIONS Weight 90-115 lbs. (41-52) kg. Shipping Weight 105-130 lbs. (48-59 kg.) Weight Limit 500 lbs. (226 kg.) ENVIRONMENTAL CONDITIONS Conditions Temperature Humidity Atmospheric Pressure Normal Use 50° (10°C) to 104° (40°C) 20% to 60% RH 98 to 105 kPa Storage &... - Page 15 THIS PAGE IS INTENTIONALLY LEFT BLANK...
-
Page 16: Contact Information
USER MANUAL OAKWORKS ® Treatment Tables CONTACT INFORMATION: Inc. ® akworks 923 East Wellspring Road New Freedom, PA 17349 Phone: 717-235-6807 FAX: 717-235-6798 www.oakworks.com For user manuals & instructional videos related to your product, please visit http://www.oakworks.com/manuals.asp Manual Part Number MMMNST0005-EN...
