User MANUAL
OAKWORKS
®
300 Series Procedure Chair
made in the USA
with US & imported parts
www.oakworksmed.com · 717.235.6807

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 300 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for OAKWORKS 300 Series

  • Page 1 User MANUAL OAKWORKS ® 300 Series Procedure Chair made in the USA with US & imported parts www.oakworksmed.com · 717.235.6807...
  • Page 2 OAKWORKS , Inc. tial damages in connection with or ® arising out of the furnishing, per- formance, or use of this document OAKWORKS is a registered and the program material which it ® trademark of OAKWORKS , Inc. describes. ®...
  • Page 3: Table Of Contents

    Product Use Description ..................... 1 Important Safety Instructions Symbol Identification ....................1 Safety Instructions .....................1-2 Product Description & Photo 300 Series Procedure Chair ..................3 Installation Grounding ........................4 Directions for Use Hand Control Operations .................... 5 Foot Control Operations ....................6 Swivel Base Use ......................
  • Page 4: Product Use Description

    PRODUCT USe DeSCRIPTIOn / IMPORTAnT SAfeTy InSTRUCTIOnS PRODUCT USe DeSCRIPTIOn The Procedure Chair is a powered positioning examination table used to support the patient during medical procedures. It is intended to be operated by a healthcare professional in a medical environ- ment.
  • Page 5 Close supervision is necessary when this furnishing is used near children or disabled persons. The Oakworks Procedure Chair has two lifting columns that raise and lower the chair and three actuators that allow the client to be positioned for both client and therapist comfort. Each of these devices has a duty cycle of approximately 10%, meaning 2 minutes of operation within a 20 minute period.
  • Page 6: Product Description & Photo

    PRODUCT DeSCRIPTIOn 300 Series Procedure Chair Adjustable Head rest (accessory) 12 Button Hand Control electric adjustment electric 0° to 80° Back rest Paper roll Holder (1) self-Adjusting removable Arm rests (2) (accessory) retractable Foot rests Fixed T-rail (stirrups) (2) (option)
  • Page 7: Installation

    InSTAllATIOn The Procedure Chairs come completely assembled and ready to use. Plug the cord into a functioning out- let that is rated for the table. (see Grounding below) Arrange the power cord and control cords so that they will not create a tripping hazard and where the controls are located to your liking and are conveniently accessible.
  • Page 8: Directions For Use

    DIReCTIOnS fOR USe hAnD COnTROl OPeRATIOnS CAUTIOn Do not sit on the Fowler (Backrest) or Leg Rest sections. Do not leave the patient unat- tended. When lowering the chair or using the Trendelenburg functions, make sure there is nothing that can impede motion (like stools, cabinets, accessory parts, cleaners, etc.) The Multi-function Hand Control operates all functions by holding down one button at a time.
  • Page 9: Foot Control Operations

    DIReCTIOnS fOR USe fOOT COnTROl OPeRATIOnS CAUTIOn Do not sit on the Fowler (Backrest) or Leg Rest sections. Do not leave the patient unat- tended. When lowering the chair or using the Trendelenburg functions, make sure there is nothing that can impede motion (like stools, cabinets, accessory parts, cleaners, etc.) The Multi-function Foot Control operates all functions by holding down one button at a time.
  • Page 10: Swivel Base Use

    DIReCTIOnS fOR USe SWIvel bASe USe CAUTIOn When rotating the chair, make sure there is nothing around the chair that can impede the rotational motion (like stools, cabinets, etc) rotate up º to 240 The chair can be rotated with a patient in it. Locate the black push buttons at the top of the back rest section. Press in and hold either one of the buttons to disengage the base locking mechanism.
  • Page 11: Head Rest Use

    DIReCTIOnS fOR USe heAD ReST USe CAUTIOn Do not extend the dowels more than 4” (10 cm.) from the Back Rest section. Adjustable large The Adjustable head rest The Large head rest is angle is adjusted using a adjusted by using the knob. locking knob.
  • Page 12: Procedure Tray Use

    DIReCTIOnS fOR USe PROCeDURe TRAy USe CAUTIOn Make sure the Leg Rest is fully lowered before using the procedure tray. Do not sit or push on the Procedure Tray when extended from the seat. Maximum Weight rating of 15 lbs. (6.8 kg.) Slide out the Procedure Tray by pulling on the center slot of the tray holder until the...
  • Page 13: Arm Rest Installation And Adjustment

    DIReCTIOnS fOR USe ARM ReST InSTAllATIOn AnD ADjUSTMenT CAUTIOn Do not use the arm rest for patient support during the mounting or dismounting of the chair. The arm rest is not designed to support the patient’s weight. TO InSTAll The ARM ReSTS: The Arm Rests adjust automatically as the back rest moves to remain parallel to the floor.
  • Page 14: Procedure Chair Face Rest Crescent

    DIReCTIOnS fOR USe PROCeDURe ChAIR fACe ReST CReSCenT The Procedure Chair Face Rest Crescent is designed to be used for prone positioning. An Adjustable Head Rest is required for this accessory. T-RAIl ADAPTeR The T-Rail Adapter can be attached at designated locations on one or both sides of the back rest sec- tion, allowing the use of any t-rail accessory.
  • Page 15: Cleaning & Disinfection

    MAINTENANCE • No specific maintenance tasks are required. • Oakworks medical tables/chairs are designed and built to provide many years of dependable service. Please follow local regulations and laws when disposing of the electrical components used in this chair. For all Customer Service related problems refer to the Service Manual •...
  • Page 16: Model Number & Serial Number

    ANSI/AAMI STD ES60601-1 IEC STD 60601-1-6 Serial Number Ser#: PC1565022 Certified to CAN/CSA STD C22.2 No. 60601-1 PCM 300 Series 27 x 19-35 x 74 3M/TT/XXH8BK TTSKYBLUE 01/04/2013 Order#:654321 Notes: Sample Product Label European Authorized Representative: Emergo Europe Molenstraat 15...
  • Page 17: Specifications

    SPeCIfICATIOnS PRODUCT SPeCIfICATIOnS Weight 280-325 lbs. (127-148 kg.) shipping Weight 372-417 lbs. (169-189 kg.) Lifting Capacity 550 lbs. (250 kg.) envIROnMenTAl COnDITIOnS Conditions Temperature Humidity Atmospheric Pressure Normal Use 50° (10°C) to 104° (40°C) 20% to 60% rH 98 to 105 kPa storage &...
  • Page 18: Guidance And Manufacturer's Declaration - Electromagnetic Emissions

    SPeCIfICATIOnS Guidance and manufacturer’s declaration - electromagnetic emissions The chair is intended for use in the electromagnetic environment specified below. The customer or the user of the chair should assure that it is used in such an environment. emissions Test Compliance electromagnetic environment - guidance The chair uses rF energy only for its internal...
  • Page 19: Guidance And Manufacturer's Declaration - Electromagnetic Immunity

    SPeCIfICATIOnS Guidance and manufacturer’s declaration - electromagnetic immunity The chair is intended for use in the electromagnetic environment specified below. The customer or the user of the chair should assure that it is used in such an environment. electromagnetic Immunity Test IeC 60601 test level Compliance level environment - guidance...
  • Page 20: Electromagnetic Immunity

    SPeCIfICATIOnS Guidance and manufacturer’s declaration - electromagnetic immunity The chair is intended for use in the electromagnetic environment specified below. The customer or the user of the chair should assure that it is used in such an environment. Immunity Test IeC 60601 test level Compliance level electromagnetic environment - guidance...
  • Page 21 ThIS PAGe IS InTenTIOnAlly lefT blAnK...
  • Page 22 ThIS PAGe IS InTenTIOnAlly lefT blAnK...
  • Page 23 ThIS PAGe IS InTenTIOnAlly lefT blAnK...
  • Page 24: Contact Information

    User MANUAL OAKWORKS ® 300 Series Procedure Chair COnTACT InfORMATIOn: Inc. ® akworks 923 East Wellspring Road New Freedom, PA 17349 Phone: 717-235-6807 FAX: 717-235-6798 www.oakworksmed.com 3034177 CONFORMS TO: ANSI/AAMI STD ES60601-1 IEC STD 60601-1 3RD EDITION IEC STD 60601-1-2 3RD EDITION IEC STD 60601-1-6 3RD EDITION CERTIFIED TO CAN/CSA STD C22.2 NO.
