Operation of the Sunny Central String-Monitor
11.3 Spot Values
Recalling spot values
1. Log into the Sunny WebBox as an installer.
2. Go to "System > Devices" on the web interface.
3. Select Sunny Central String-Monitor Controller "SCSMC" or Sunny Central String-Monitor
"SSM-US" from the list.
4. Click the "spot values" tab.
11.3.1 Spot values Sunny Central String-Monitor Controller
Name
Error
h-On
MeanCurGr1 –
MeanCurGr6
Mode
ParaCfg
SSMUIntDatTm Display of the time duration for one complete communication cycle between
SSMUNoOf
SSMUWrnCode
64 SSMUS-TUS094511
Description
Warning indicator Sunny Central String-Monitor Controller (see Section
12.2 "Confirm warning" (page 75)).
Total hours in operation.
Mean value of electricity generated by the respective group.
Operating mode of the Sunny Central String-Monitor Controller:
• Operation
• Warning
• Disturbance
• Error
Ok: The configuration is in order.
WrnMoniTmCom: end time of the communication period is before the start
time.
WrnMoniTmGr: at least one end time in a given group is before the respective
start time.
the Sunny Central String-Monitor Controller and the connected Sunny Central
String-Monitors.
Number of Sunny Central String-Monitors found.
If a string failure is recognized, the following values are indicated:
• Identification number of the Sunny Central String-Monitor.
• First position after the decimal point: the number of the current
measurement input (1 - 8).
