Identifying The Sunny Central String-Monitor - SMA SUNNY CENTRAL STRING-MONITOR US Technical Description

Unpacking
3.3 Identifying the Sunny Central String-Monitor
The Sunny Central String-Monitor can be identified with
the type label (see image on the right). The type label is
located on the inside of the Sunny Central String-Monitor
door.
Specified on the type plate:
Position Name
A Model
B Serial No.
C Manufacturing
Version
16 SSMUS-TUS094511
Description
The Sunny Central String-
Monitor type name with
version code (optional).
Serial number of the Sunny
Central String-Monitor.
Manufacturing version of
the Sunny Central String-
Monitor.
SMA Solar Technology AG
SMA Solar Technology AG
www.SMA.de
SUNNY CENTRAL
String-Monitor US
Model
Serial No.
SSM-US: 20 107
Fabrication Version: P02
Fabrication Date: 09/2009
This unit approved for use in DC circuits only
Max. system voltage under all conditions 600V DC
Operating voltage range (Vdc)* 0 - 600 V DC
Max. string current * 5.1A DC
Max. continuous current* 328 A DC
Max. operating current* 480 A DC
Short circuit rating* 512 A DC
Operating temperature range*
-13°F to +122°F (-25°C to +45°C)
Enclosure: Type 4R (IP54)
* For more details and for tightening torque, allowable wire
size and type see the Operator's Manual
PV Array Combiner
LISTED UL 1741
Technical Description
A
B
C
