VGA CAT5/5E/6 EXTENDER

5.0 CONNECTION AND OPERATION

1) Connect the single VGA source to the main VGA input using a piece of VGA cable.
2) Connect VGA output of the Sender to a local display and Audio output of the Sender to a local Sounder
3) Connect Sender and each Receiver using a piece of each pieces of CAT-5e/6
4) Connect VGA outputs of Receivers to remote displays and Audio output of Receivers to remote sounders.
5) Plug one 5V@ 2A power supply into the VGA UTP 1X1Splitter and the others 5V@2A power suppliers to Receiver.
Attention: Insert / Extract cable gently.
5.1 CONNECTION DIAGRAM
VGA IN AUDIO
6.0 SAFETY PRECAUTIONS
C A U T I O N
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Maintenance:
Clean only with a dry cloth. Do not use cleaning solvents or abrasives.
Warranty:
No guarantee or liability can be accepted for any changes and modifications of the product or damage caused due
to incorrect use of this product.
This product is marked with this symbol. It means that used electrical and electronic products should
not be mixed with general household waste. There is a separate collections system for these products in
compliance with EU Directive WEEE 2002/96/EC
The product is compliance with European Directive EMC 2004/108/EC.
Computer
VGA OUT
To reduce risk of electric shock, this product should ONLY
be opened by an authorized technician when service is
required. Disconnect the product from mains and other
equipment if a problem should occur. Do not expose the
product to water or moisture.
Display
AUDIO VGA OUT
Cat 5e/6 Cable
AUDIO
EN
