The Main Screen

Display Settings
The mode will be displayed at the top of the screen, between the signal strength indicator and the battery level indicator.
Depending on your setting selections, the clock, the channel or the group will be displayed in the center of the screen. Channel
or Group is determined by your mode. A large or small clock is determined by the Master 1 settings.
To change any of these settings, hold down the menu button. For instructions on configuring the Digi-Wave system, see "Basic
Settings" on page 10.
Signal Strength Indicator
When a Master 1 is available on the group or channel, the signal strength indicator on DLR Receivers and Guests will indicate
how strong the signal is.
When a Master 1 is not available OR while the Master 1 is changing settings that may affect other devices, the icon will
disappear. Once the Master 1 has been set up, the DLR Receiver and other DLT transceivers should rejoin the group or channel
automatically (with some exceptions, such as a Security PIN being set).
Attendee Checking
The number of DLT transceivers currently talking will be displayed in the bottom right corner box. It does not count DLR
Receivers because they do not have a talk button.
Priority Indicator
A label indicating Master 1, Master 2 or Guest will appear on the lower left of the screen on the main screen.
If the label is blinking, the device has not had its settings configured. Enter the menu system to begin configuring the device.
Setting Up the Digi-Wave™ System
Settings of the Digi-Wave system should be selected based on how the system will be used. A Master 1 device will declare
a majority of the settings and pass these settings to devices that connect with it. Since the Master 1 automatically sets most
settings, there is little to be set up on Guest devices for basic usage of the Digi-Wave system.
For more information on terminology and a general system overview, see "Before Programming the Digi-Wave™ System" on
page 7.

Language

The Digi-Wave menu is available in multiple languages. Select the language you desire for set up.

Initial Setup

New Settings
To start from the very beginning with your Digi-Wave settings, select New Settings. This will start you at the beginning of the set-
up process where you can set Basic Settings (see "Basic Settings" on page 10).
When a DLR Receiver or a DLT transceiver is first started, some settings will need to be selected
before the device can be used. There are three ways to load settings on a Digi-Wave device:
Digi-Wave 400 Series
9
