PCAN-Router Pro FD – User Manual
3

Operation

3.1

Ensuring Power Supply

The PCAN-Router Pro FD must be supplied as standard with a
nominal 12 V (8 to 32 V possible) DC voltage via the power
connection.
Note: If you install a backup battery (see section 4.4) and it is
charged, the device can also be operated without a power
supply (e.g. in the event of a power failure).
3.2

Starting the PCAN-Router Pro FD

The PCAN-Router Pro FD is automatically switched on when the
supply voltage is applied (power LED lights up). By default, six
transceiver modules with wake-up function are installed.
If other transceiver modules without wake-up function are installed
on request, an external wake-up signal via pin 1 of the power
connector is required (see section 4.1 on page 13).
12
