PCAN-Router Pro FD – User Manual
Power supply
Supply voltage
Current consumption
Wake-up time
Auxiliary voltage RTC
Backup battery (optional)
Microcontroller
Type
Clock frequency
Memory
Optional memory (external)
Firmware upload
Data logging
Internal memory
External memory (optional)
Maximum size of a
recording
Recording format
Environment
Operating temperature
Temperature for storage
and transport
Relative Humidity
Protection class (IEC 60529)
12 V DC, 8 to 30 V DC possible
Idle:
Maximum:
16 ms
Button cell CR1620 3.0 V
Lithium accumulator with 3.6 V and 3.4 Ah
18650 form factor; protection against short circuit,
overcharging and low charge protection required
STM32F765NIH6 (based on Arm® Cortex® M7)
200 MHz
32 MByte SDRAM
SD-Karte
via CAN (PCAN interface required)
16 GByte pSLC eMMC
SD card
2 GByte
Proprietary binary format (*.btrc),
Conversion options with the supplied
Windows program:
- PCAN-Trace (*.trc)
- Vector trace (*.asc)
- comma separated values (*.csv)
-40 - 85 °C (-40 - 185 °F)
-40 - 100 °C (-40 - 212 °F)
15 - 90 %, non-condensing
IP20
30
400 mA
1 A
