PCAN-Router Pro FD – User Manual
Attention! Electrostatic discharge (ESD) can damage or destroy
components on the card. Take precautions to avoid ESD.
Do the following to install the backup battery:
1. Disconnect the device from the power supply.
2. Remove the eight screws at the front and back of the
housing.
3.
Only with optional BroadR-Reach® interface:
Remove the two fastening screws of the D-Sub connector
on the rear of the housing.
4. Remove the back panel and housing cover.
5. Pull the board out of the housing in the direction of the front
side.
6. Insert the backup battery with integrated protection (form
factor 18650) according to the polarity.
7. Fasten the battery with a cable tie in the recesses provided.
8. Push the board back into the first rail of the housing.
9. Replace the housing cover and the back panel.
10. Only with optional BroadR-Reach® interface:
Fasten the two screws of the D-Sub connector to the rear of
the housing.
11. Reinsert all eight housing screws.
Important note: Only use batteries with integrated PCB
protection to avoid short circuit, overcharging, and deep
discharge! We recommend using a lithium-ion battery such as
the Soshine 18650 3600 mAh 3.7 V or comparable models.
