PCAN-Router Pro FD – User Manual
Appendix A
On request, the PCAN-Router Pro FD can be equipped with an
Ethernet interface via an RJ-45 socket or with a BroadR-Reach®
interface via a D-Sub connector.
Ethernet interface via RJ-45 Socket
Optional
Interfaces
Figure 19: Ethernet interface via RJ-45 socket
on the back of the housing (only on request)
Pin Signal
1
2
3
4
5
6
7
8
9
Tx+
Tx-
Rx+
-
-
Rx-
-
-
-
