Pro-OX 1650 Iron Filter Installation & Startup Guide
Fig 3—CWS 165 valve from the rear showing the inlet (left) and outlet (right) end-connector fittings (1" or
1-1/4" NPT in Noryl plastic). Brass end-connectors are also available for connecting to copper tubing.
Inlet
Outlet
Fig 4—CWS 165 side view
Drain Line
Bypass Knobs (bypass position)
Outlet
Inlet
www.cleanwaterstore.com
Rev 080814
Page 7
