Parts List - Linear Technology DC1884A Series Demo Manual

PARTS LIST

ITEM QTY REFERENCE
DC1884A1
1 5 C1, C69, C81, C94, C107
2 0 C2
3 0 C3, C6
4 19 C4, C8, C9, C58, C59, C65, C66, C71,
C72, C77, C78, C84, C85, C90, C91,
C97, C98, C103, C104
5 10 C5, C7, C60, C67,C73, C79, C86, C92,
C99, C105
6 1 C10
7 2 C11, C12
8 1 C13
9 3 C14, C55, C56
10 16 C57, C61, C62, C64, C68, C74, C76,
C80, C83, C87, C89, C93, C96, C100,
C102, C106
11 8 C63, C70, C75, C82, C88, C95, C101,
C108
12 3 E1, E3, E4
13 2 FB1, FB2
14 8 JP1, JP2, JP3, JP4, JP5, JP6, JP8,
JP9
15 10 J1, J2, J4, J5, J6, J7, J8, J9, J10, J11 CON, SMA STRAIGHT
16 1 J3
17 0 L1
18 8 L2, L3, L4, L5, L6, L7, L8, L9
19 8 R1, R2, R3, R6, R7, R8, R10, R85
20 5 R4, R11, R82, R83, R84
21 2 R5, R13
22 4 R9, R19, R20, R86
23 0 R14, R15, R16, R18, R24, R25, R26,
R27
24 2 R17, R23
25 10 R21, R22, R104, R114, R124, R134,
R144, R154, R164, R174
26 1 R28
27 1 R29
28 0 R87, R88, R89, R90, R91, R92, R93,
R94
29 24 R95, R96, R97, R105 TO R107, R115
TO R117, R125, R126, R128, R135 TO
R137, R145, R146, R148, R155 TO
R157, R165, R166, R168
30 16 R98, R99, R108, R109, R118, R119,
R127, R129, R138, R139, R147,
R149, R158, R159, R167, R169
DEMO MANUAL DC1884A
PART DESCRIPTION
CAP , X5R, 2.2μF 16V 20%, 0603
CAP , 0402
CAP , X7R, 0.01μF 16V 10%, 0402
CAP , X7R, 0.01μF 16V 10%, 0402
CAP , NP0, 4.7pF 25V 10% 0402
CAP , X5R, 4.7μF 6.3V, 20%, 0603
CAP , X7R, 1μF 10V, 20%, 0603
CAP , TANT 100μF 10V, 20%, 6032
CAP , X5R, 0.1μF 10V, 10%, 0402
CAP , COG, 8.2pF , 50V, 5%, 0402
CAP , X5R, 0.1μF 10V, 10%, 0603
TURRET, TESTPOINT 0.062 THICK BRD 0.094"
FERRITE BEAD, ?AMP 1206
HEADERS, SGL ROW 3 PINS 2mm CTRS
BGA CONN, 10 × 40 PIN
IND, 0603
IND, 56nH, 0603
RES, CHIP 1k, 1/16W, 5% 0402
RES, CHIP 10k, 1/16W, 5% 0402
RES, CHIP 31.6k, 1/16W, 1% 0402
RES, CHIP 100, 1/16W, 5% 0402
RES, 0402
RES, CHIP 5.1, 1/16W, 5% 0402
RES, CHIP 49.9, 1/16W, 1% 0402
RES, CHIP 3k, 1/16W, 5% 0603
RES, CHIP 180k, 1/16W, 1% 0603
RES, CHIP , 100, 1/16W, 1% 0201
RES, CHIP , 86.6, 1/16W, 1%, 0402
RES, CHIP , 33.2, 1/16W, 1% 0402
MANUFACTURER/PART NUMBER
TAIYO YUDEN, EMK107BJ225MA
TBD
OPT
AVX, 0402YC103KAT2A
AVX, 04023A4R7KAT2A
TAIYO YUDEN, JMK107BJ475MA-T
AVX, 0603ZC105MAT1A
AVX, TAJW107M010R
AVX, 0402ZD104KAT2A
AVX, 04025A8R2JAT2A
AVX, 0603ZD104KAT2A
MILL MAX 2501-2-00-80-00-00-07-0
MURATA BLM31PG330SN1L
SAMTEC TMM-103-02-L-S
CONNEX, 132134
SAMTEC, SEAM-40-02.0-S-10-2-A-K-TR
TBD
MURATA, LQP18MN56NG02D
VISHAY CRCW04021K00JNED
VISHAY CRCW040210K0JNED
VISHAY CRCW040231K6FKED
VISHAY CRCW0402100RJNED
TBD
VISHAY CRCW04025R10JNED
VISHAY CRCW040249R9FKED
VISHAY CRCW06033K00JNEA
VISHAY CRCW0603180KFKEA
OPT
YAGEO, RC0402FR-0786R6L
YAGEO, RC0402FR-0733R2L
dc1884af
7
