QUICK START PROCEDURE
Output Current: Selects the LVDS Output Drive Current.
• 1.75mA (Default): LVDS output driver current.
• 2.1mA: LVDS output driver current.
• 2.5mA: LVDS output driver current.
• 3.0mA: LVDS output driver current.
• 3.5mA: LVDS output driver current.
• 4.0mA: LVDS output driver current.
• 4.5mA: LVDS output driver current.
Internal Termination: Enables LVDS Internal Termination.
• Off (Default): Disables internal termination.
• On: Enables internal termination.
6
Outputs: Enables Digital Outputs.
• Enabled (Default): Enables digital outputs.
• Disabled: Disables digital outputs.
Test Pattern: Selects Digital Output Test Patterns. The
desired test pattern can be entered into the text boxes
provided.
• Off (Default): ADC input data is displayed.
• On: Test pattern is displayed.
Once the desired settings are selected, click "OK" and
PScope will automatically update the register of the device
on the DC1884 demo board.
