DEMO MANUAL DC1884A

QUICK START PROCEDURE

DC1884 is easy to set up to evaluate the performance of
the LTM9011 family of A/D converters. For proper mea-
surement equipment setup, refer to Figure 1 and follow
the procedure explained in the following sections.
ANALOG
INPUTS
2
GND
3V TO 6V
SINGLE-ENDED ENCODE CLOCK
Figure 1. Test Setup of DC1884
JUMPERS SHOWN IN
DEFAULT POSITIONS
DC1884A F01
dc1884af
