6.1

PCB layout

red/green LED (COM)
red LED (OC)
ST-LINK reset
red LED (PWR)
UM2591 - Rev 1
Figure 4.
LD1
LD4
SB2
LD2
Top layout
UM2591
PCB layout
CN1 ST-LINK/V2-1
Micro-B USB connector
U2
STM32G031K8T6U microcontroller
B1
RESET or user push-button
LD3
green LED (USER)
page 8/26
