STM32G0 Nucleo-32 I/O assignment

Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
UM2591 - Rev 1
Table 10. Nucleo-32 I/O assignment
Pin name
PB9 ARD_D10: SPI1_CS(2) / TIM1_CH4
PC14-OSC32_IN LSE clock input
PC15-OSC32_OUT LSE clock output
VDD VDD voltage supply
VSS Ground ARD_A4: DC2_IN13
PF2-NRST RESET – USER button
PA0 ARD_A0: ADC_IN0
PA1 ARD_A1: ADC_IN1
PA2 VCP_TX: USART1_Tx
PA3 VCP_RX: USART1_Rx
PA4 ARD_A2: ADC_IN4
PA5 ARD_A3: ADC_IN5
PA6 ARD_A6: ADC_IN6
PA7 ARD_A7: ADC_IN7
PB0 ARD_D6: PWM: TIM3_CH2
PB1 ARD_D3 - PWM: TIM3_CH4
PB2 ARD_D7: I/O
PA8 ARD_D9: PWM: TIM1_CH1
PA9 ARD_D5: TIM1_CH2 / I2C1_SCL
PC6 USER LED
PA10 ARD_D4: TIM1_CH3 / I2C1_SDA
PA11 [PA9] ARD_A5: ADC_IN15 / I2C2_SCL
PA12 [PA10] ARD_A4: ADC_IN16 / I2C2_SDA
PA13 SWDIO
PA14-BOOT0 SWCLK
PA15 ARD_D2: I/O
PB3 ARD_D13: SPI1_SCK
PB4 ARD_D12: SPI1_MISO
PB5 ARD_D11: SPI1_MOSI / TIM3_CH2
PB6 ARD_D0: USART1_RX
PB7 ARD_D1: USART1_TX
PB8 ARD_D8: I/O
STM32G0 Nucleo-32 I/O assignment
Main feature / optional feature
