2. Dryer Rear View
Illus. No. Description
1
Basket (drive) Motor Assembly
2
Blower Motor Mount Assembly
3
Idler Bearing Mount Assembly
4
Basket (tumbler) Bearing Mount Assembly
5*
Electric Service Relay Box
6
Heating Unit
7
Data Label and Installation Label
8
1/8" Compressed Air Supply Inlet (behind gusset)
9
Side Access Opening
10
Front Access Opening
11
Impellor (fan) Assembly
*
Electric service connections are made in this box.
9
