- Page 1 Front IP65 Display Series 5.7”~32” User Manual Version 1.6 Document Part No.91521110101J Please read this instructions before operating the device and retain them for future reference.
-
Page 2: Table Of Contents
5.7"~27" Front IP65 Display Series User Manual Contents PREFACE .................................3 ABOUT THIS USER MANUAL ...........................5 CHAPTER 1: INTRODUCTION ...........................6 1.1 O ................................7 VERVIEW 1.2 P ..............................7 RODUCT EATURES 1.3 P ..............................7 ACKAGE ONTENTS 1.4 P ..............................8 RODUCT VERVIEW 1.5 C ............................9... -
Page 3: Preface
Preface Preface Copyright Notice No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior written permission of the original manufacturer. Trademark Acknowledgement Brand and product names are trademarks or registered trademarks of their respective owners. - Page 4 5.7"~27" Front IP65 Display Series User Manual Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury. These are Notes, Important, Cautions, and Warnings. The following is an example of each type of advisory.
-
Page 5: About This User Manual
This User Manual provides information about using the Winmate® Front IP65 Display Series. The documentation set provides information for specific user needs, and includes: Front IP65 Display Series User Manual – contains detailed description on how to use the display, its components and features. -
Page 6: Chapter 1: Introduction
5.7"~27" Front IP65 Display Series User Manual Chapter 1: Introduction This chapter gives you product overview, describes features and hardware specification. You will find all accessories that come with the display device in the packing list. Mechanical dimensions and drawings included in this chapter. -
Page 7: Overview
Part No. 9B0000000418 *Notice: Screw bolts provided by Winmate only to be used to screw the display onto a console from the rear side. If you prefer your own bolts, please make sure to use M4 and 30mm in length. -
Page 8: Product Overview
5.7"~27" Front IP65 Display Series User Manual 1.4 Product Overview This section describes physical appearance of the Front IP65 Display Series. Note: Notice that standard input terminals include VGA and HDMI. Your device may be equipped with other input terminals based on your order. -
Page 9: Connector Description
Chapter 1: Introduction 1.5 Connector Description Display input and output connectors are located on the bottom side. Notice that input and output connectors may vary by product size and specifications. Item Description Power Jack – Connects computer to source of power. USB for Touch - Connects USB for touch capabilities. -
Page 10: Osd Control Panel
5.7"~27" Front IP65 Display Series User Manual 1.6 OSD Control Panel 1.6.1 OSD Control Panel Location The location of the OSD control panel may vary by model. Please refer to product datasheet for more details. 1.6.2 Control Buttons OSD control panel varies by product specifications. Refer to a product datasheet to check the OSD control panel type of a particular model. - Page 11 Chapter 1: Introduction Type B Buttons Icon Function Decrease the value / Select up Increase the value / Select down Power switch Select left / Exit / Auto adjustment Auto Select right / Call main OSD menu / Enter Menu LED Indicators Description Icon...
-
Page 12: Brightness Adjustment Knob
5.7"~27" Front IP65 Display Series User Manual LED Indicators Description Function Power Lights up in "Green" when the monitor turn on Stand by Lights up in "Orange" when the device cannot detect any input source Type D Buttons Icon Function... -
Page 13: Chapter 2: Installation
Chapter 2: Installation Chapter 2: Installation This chapter provides hardware installation instructions and mounting guide for all available mounting options. Pay attention to cautions and warning to avoid any damages... -
Page 14: Wiring Requirements
éviter le risque de blessure. 2.2.1 Panel Mount The Front IP65 Display Series comes with clamp mounts that enable you to install the unit onto a wall (where space has been cut out to accommodate the rest of the hardware). Winmate provides VESA by request. -
Page 15: Vesa Mount
❷ ❸ ❹ 2.2.2 VESA Mount Front IP65 Display Series comes with VESA Mount holes for mounting. Installation Instruction: 1. Screw VESA bracket to the fixture (ex. swing arm) with four VESA screws. 2. Place the device on VESA bracket. -
Page 16: Cable Mounting Considerations
2.4 Connecting Power This section provides information on how to use connectors on the Front IP65 Display Series. Be cautious while working with these modules. Please carefully read the content of this chapter in order to avoid any damages. -
Page 17: Connecting Peripherals
Chapter 2: Installation 2.5 Connecting Peripherals The panel control port is designed for monitors that work with a variety of compatible video sources. Due to the possible deviations between these signal sources, you may have to make adjustments to the monitor settings from the OSD menu when switching between these sources. -
Page 18: Dvi Connector
5.7"~27" Front IP65 Display Series User Manual 2.5.4 DVI Connector Use DVI cable to connect your TFT LCD display to the external PC system. Fasten cable connectors with screws. Pin assignment and signal names of DVI connector Pin № Signal Name Pin №... -
Page 19: Display Port Connector
Chapter 2: Installation 2.5.7 Display Port Connector Use Display Port cable to connect your TFT LCD display to the external PC system. Pin assignment and signal name of Display Port connector Pin No. Signal Name Pin No. Signal Name Lane 0 P Lane 0 N Lane 1 P Lane 1 N... -
Page 20: Chapter 3: Operating The Device
5.7"~27" Front IP65 Display Series User Manual Chapter 3: Operating the Device In this chapter you will find instructions on how to operate the display. -
Page 21: Turning On The System
Chapter 3: Operating the Device 3.1 Turning on the System To turn on the system: 1. Connect the power adapter cable to the DC IN of the display. 2. Connect the power cord to the power adapter. 3. Connect the power cord to a power outlet. 4. -
Page 22: Osd Menu Navigation
5.7"~27" Front IP65 Display Series User Manual 3.2 OSD Menu Navigation The OSD menu varies based on your OSD control panel. For 5 Key OSD Control Panel Type A Type B OSD Icon Sub-menu Settings Note BRIGHTNESS slider bar Default 50 Use to adjust the screen’s brightness. - Page 23 Chapter 3: Operating the Device OSD Icon Sub-menu Settings Note USER R.G.B slider bar Default USER Choose RED/GREEN/BLUE to set value of color temperature brightness to suit your own preference 9300K Select and execute Use to set value of display for the CIE coordinate 9300 color temperature 6500K Select and execute COLOR...
- Page 24 5.7"~27" Front IP65 Display Series User Manual For 8 Key OSD Control Panel Type C Type D OSD icon Sub-menu Settings Note BRIGHTNESS slider bar Adjusts the overall image and background brightness. Press “ ” or “ ” to adjust.
- Page 25 Chapter 3: Operating the Device OSD icon Sub-menu Settings Note AUTO SETUP PRESS YES TO AUTO SETUP *VGA CHANNEL ONLY Automatically adjusts screen size, H position, V position, Clock, Clock Phase AUTO ADJUSTMENT ON/OFF *VGA CHANNEL ONLY H Position, V Position and Clock Phase are adjusted automatically upon power on. H POSITION slider bar *VGA CHANNEL ONLY...
- Page 26 5.7"~27" Front IP65 Display Series User Manual OSD icon Sub-menu Settings Note OSD TURN OFF slider bar Turns off the OSD after a period of inactivity. The preset choices are 0-60 seconds. H - slider bar OSD POSITION V - slider bar Determines the location where the OSD appears on the screen.
-
Page 27: Troubleshooting Guide
Chapter 3: Operating the Device 3.3 Troubleshooting Guide If your display fails to operate correctly, check the following chart for possible solution before calling for repairs: Condition Check Point Check if the signal cable is firmly seated in the socket. The picture does ... -
Page 28: Chapter 4: Technology
5.7"~27" Front IP65 Display Series User Manual Chapter 4: Technology This chapter describes technology behind selected display series, including wide temperature and transflective technology. -
Page 29: Wide Temperature Technology
Chapter 4: Technology 4.1 Wide Temperature Technology Our selected TFT-LCD modules are designed to deliver optimum performance over a wide range of temperatures from -20°C to +60° C in order to accommodate for diverse industrial applications such as outdoor kiosks in winter and summer. How does this technology work? With our heater electronic control mechanism with temperature sensors, the heater control board can control the heater on or off and then regulate the internal system temperature... -
Page 30: Transflective Technology
5.7"~27" Front IP65 Display Series User Manual 4.2 Transflective Technology Transflective TFT display features a transparent reflector in front of the backlight. The incoming light is reflected and used to illuminate the TFT display. Transflective LCD modules hold both transmissive and reflective properties, and the method of image display depends upon the conditions of the ambient environment. -
Page 31: Appendix
Appendix Appendix This chapter contains additional product information, including troubleshooting guide and frequency table... -
Page 32: Appendix A: Resolution Table
5.7"~27" Front IP65 Display Series User Manual Appendix A: Resolution Table V-VGA, D-DVI, H-HDMI Resolution Support Table 15.6"/18.5"/ 5.7"/ 8"/ 8.4"/ 7"/ 10.4"/ 10.1"/ 15.6"/ 20.1"/ Panel Size 7" 17"/19" 21.5"/23.8"/27"/ 10.1"/ 24" 6.5" 12.1" 10.1" 12.1"/15" 12.1" 18.5" 23.1"... -
Page 33: Appendix C: Product Dimensions
Appendix Appendix C: Product Dimensions Dimensions Cutout VESA Model Name (W x H x D, mm) (W x H, mm) (W x H, mm) R05T100-IPD1HB 198 x 162 x 41 mm 170 x 138mm R06L200-IPA1 218 x 164 x 50 mm 191 x 142mm R08L200-IPU1 275 x 216 x 56 mm... - Page 34 5.7"~27" Front IP65 Display Series User Manual Product Mechanical Drawing Unit: W x H x D, mm Cutout...
- Page 35 Notes ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________...
- Page 36 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C www.winmate.com Copyright © Winmate Inc. All rights reserved.
