Terminals:
Terminal/pin
X13:1
X13:2
X13:3

Ethernet Interface for IEC 60870-5-104 and Service Port

There is an Ethernet interface, RJ45 10 / 100Base - TX Full Duplex, for communication via IEC 60870-5-104
and the remote control center.
This interface is also used as a service port, i.e., for connecting a service computer via TCP / IP and accessing
the built-in web interface of IPC402x.

USB Port

IPC402x is equipped with a service port for USB Type B. The port is located on the right of the front panel
next to the local acknowledge push-button.

Secondary Current Inputs

Current terminals for phase current transformers are found in the following locations:
▪
Detector 1: Terminals X1-X3 between the RJ45 connector for Ethernet and the terminal for power
supply.
▪
Detector 2: Terminals X21-X23, located at the lower side of the expansion module (left).
▪
Detector 3: Terminals X31-X33, located at the upper side of the expansion module (left).

Power Supply

IPC402x requires an external power supply of 24-48 VDC which is connected to terminal block X4. The
connection is not polarity sensitive.
The unit must be connected to protective ground via X4.2.
Protrol AB
Alfagatan 3
431 49 Mölndal, SWEDEN
Short name Description
RX/TX+ Sender/Receiver (plus)
RX/TX- Sender/Receiver (minus)
TERM Line termination. Connect to X13:2 for activation.
